| Specifications |
| Sensor type |
CMOS |
| Sensor size |
1/3" |
| Imaging area |
5.44x3.07mm |
| Capture resolution |
4MP (2592x1520 pixels) |
| Live display mode through Wi-Fi |
1280x720, 1920x1080 pixels (Full HD) |
| Live display mode through Ethernet |
1280x720, 1920x1080 pixels (Full HD) |
| Pixel size |
2.0x2.0µm |
| Scan mode |
Progressive |
| Data transfer |
Wi-Fi (2.4 & 5 GHz), Ethernet |
| Max. frames per second (fps) |
1920x1080 @ 30 fps, 1280x960 @ 30 fps (depending on Wi-Fi strength) |
| Exposure time |
0.03 msec to 0.03 sec |
| Operating temperature |
From 0 to +60 degrees celsius non condensing |
| Max. signal to noise ratio |
38.3dB |
| Dynamic range |
64.6dB |
| Sensitivity |
1.9V/Lux-sec |
| Buttons |
On/Off |
| Support device |
Universal Web browser (HTML5) |
| Supported OS |
Windows XP/Vista/7/8/10 and MAC OSX, Linux, Android 4.0 or higher, iOS 7 or higher |
| Minimum computer requirements |
2GHz dual core - RAM memory 2GB - Video memory min. 512 MB |
| Lens mount |
C-Mount |
| Focusable lens |
12mm |
| Software |
Motic Images Plus 3.0 for Windows, OSX and Linux, MotiConnect App for iOS and Android |
| Functions |
Still image and video capture, live and still image measurmenets, image adjustments, white balance, automatic & manual exposure, individual objective calibration system. |
| Power supply |
5V (External Power supply) |
| Package includes |
CS ring adaptor, focusable lens, 30mm and 38mm eyepiece adapters, USB 2.0 cable, Motic 4 dot calibration slide, macro tube, Motic Images Plus 3.0 PC/OSX/Linux |
