| General Specifications |
| |
100 |
300 |
500 |
| Flash Range (FPM/RPM): |
30 to 999,999 |
| Display: |
6 digit numeric and 5 digit alphanumeric LCD reflective |
6 digit numeric and 5 digit alphanumeric LCD with touch keypad. High contrast blue background/ white characters with backlight |
| Accuracy/Resolution: |
0.001% of setting or ±1 lsd/6 digits to 0.001 |
| Light Source: |
12 LED Array |
12 High Output LED Array |
| Flash Duration: |
Adjustable to 14 degrees/1000 µsecs max |
| Light output: |
3400 Lux @ 6000 FPM, 12 inches (30.48cm), 2° duty cycle, Max light output: 24,000 Lux |
5500 Lux @ 6000 FPM, 12 inches (30.48 cm), 2° duty cycle, Max light output: 30,000 Lux |
| Color Temperature: |
approx. 6200°K |
| External Triggers in/out: |
N/A TTL (12Vdc Max) Input. Provides 3.3 Vdc TTL output |
| Tachometer Mode: |
0-999,999 RPM with integral laser (Optional) 0-999,999 RPM with integral laser or external input |
| Programmable Memory: |
N/A |
Yes (10 set points) |
| Internal Phase Shift: |
N/A |
Yes |
| Phase Delay - degrees: |
N/A |
-360.0 to 345.0 degrees |
| Time Delay - milliseconds: |
N/A |
-50.000 to 50.000 msec Virtual RPM |
| (Slow Motion): |
N/A |
-60.0 to 60.0 VRPM |
| Operating Time: |
Standard battery pack: 9.5 hours typical (6000 FPM, 2° duty cycle) Hi-capacity battery pack (optional): 19 hours typical (6000 FPM, 2° duty cycle) |
| Power Supply (Battery): |
Removable/rechargeable Standard Li-Ion battery pack with 115/230 50/60Hz recharging station |
Removable/rechargeable Standard Li-Ion battery packs (Qty. 2) with 115/230 50/60Hz recharging station |
| Power Supply (A/C): |
115/230 Vac 50/60Hz AC adapter with 6 foot (2M) cable and interchangeable outlet adapters (Optional) |
| Weight: |
1.4 Lbs. (635 grams) with Standard battery
1.5 Lbs. (680 grams) with Hi-capacity battery |
| Size (H x W x D): |
9.5 x 3.75 x 5.5 in. (241 x 95 x 140mm) |
| Housing material/rating: |
ABS/IP54 |
