| Specifications |
| General |
| Record |
Sample Rates: User configured 1 every 2 seconds to 1 every 24 hours
No. of Samples: 32,000 or 64,000 (depends on config) |
| Record Trigger |
Two independent triggers. Multiple trigger modes: Instantaneous, button control, on alarm, time and date (start and stop), day of week or on event only. |
| Record Mode |
Fill to end of memory; Cyclic, number of samples, time duration |
| Display |
4 digit LCD (Non display versions available with LED only)
User programmable: Indication of data value, eng units, alarms, record mode, battery condition, time/date, memory |
| LED |
User programmable: Indication of alarms, recording, triggered |
| Button |
User programmable: View display, record on/off, reset alarms, reset timer |
| Alarms |
2 user programmable alarms. High or Low |
| Communication |
Direct USB connection |
| Software |
Track-It - Program device, view data (historic or real time), export to Excel. Simple and advanced modes |
| Battery |
Coin Cell Option: Battery: Lithium CR2032, |
| Life |
12-15 months @ 1 minute sample rate
Hi Energy Option: Battery: EF651625, Life: 3 to 5 years @ 1 minute sample rate |
| Dimensions |
4.06” (10.32cm)L x 0.66” (1.67cm)H x 1.00” (2.54cm)W |
| Measurement |
| Voltage Range |
120 to 240 Vac parallel (voltage triggered, optically isolated) |
| Clock Accuracy |
± 1 minute/year |
| Temperature Range |
-20 to +85°C /-4 to 185°F w/EF65162 battery
-20 to +70°C /-4 to 158°F w/CR2032 battery |
| Accuracy |
±0.5°C 0 to 50°C / 32 to 122°F
±2°C –20 to 85°C / -4 to 185 F |
| Resolution |
0.06°C / 0.11°F |
| Clock Accuracy |
± 1 minute/year |
