General Specifications |
Interior |
Stainless steel, material 1.4301 (ASTM 304), deep-drawn |
Internals |
Stainless steel grids, electropolished (sizes 30 and 55: 1, sizes 110 to 1060: 2) |
Housing |
Textured stainless steel, rear zinc-plated steel, intuitively operated SingleDISPLAY or TwinDISPLAY (TFT colour display) with touchscreen |
Double doors |
Outside stainless steel, fully insulated, inside glass (sizes 750 and 1060 two-leaves) |
Connection |
Mains cable with plug (German type) |
Installation |
4 feet; sizes 400 – 1060 mounted on lockable castors |
Interfaces |
(only TwinDISPLAY) |
Stainless steel interior |
Volume |
approx. l |
32 |
53 |
108 |
256 |
384 |
749 |
1060 |
Width (A) |
mm |
400 |
400 |
560 |
640 |
640 |
1040 |
1040 |
Height (B) |
mm |
320 |
400 |
480 |
800 |
1200 |
1200 |
1200 |
Depth (less 10 mm for fan – Peltier) (C) |
mm |
250 |
330 |
400 |
500 |
500 |
600 |
850 |
Stainless steel grids, electropolished (standard equipment) |
number |
1 |
2 |
|
|
|
|
Max. number of grids/shelves |
number |
3 |
4 |
5 |
9 |
14 |
Max. loading per grid/shelf |
kg |
20 |
30 |
20 |
Max. loading of chamber |
kg |
60 |
80 |
150 |
200 |
Textured stainless steel exterior |
Width (D) |
mm |
585 |
585 |
745 |
824 |
824 |
1224 |
1224 |
Height (sizes 400, 750, 1060 with castors) (E) |
mm |
704 |
784 |
864 |
1183 |
1720 |
1726 |
1661 |
Depth (without door handle), door handle + 56 mm (F) |
mm |
506 |
586 |
656 |
756 |
756 |
856 |
1107 |
Further data |
Electrical load at 230/115 V, 50/60 Hz |
approx. W |
140 |
275 |
550 |
820 |
1100 |
1300 |
1500 |
Working-temperature range without light |
°C |
0 (at least 20 below ambient temperature) to +70 |
Working-temperature range with light |
°C |
+10 to +40 |
– |
|
Setting temperature range |
°C |
0 to +70 |
Setting accuracy |
°C |
0.1 |
Packing data |
Net weight |
approx. kg |
40 |
52 |
78 |
114 |
157 |
230 |
255 |
Gross weight (packed in carton) |
approx. kg |
56 |
71 |
103 |
165 |
210 |
301 |
419 |
Width |
approx. cm |
66 |
73 |
83 |
93 |
93 |
133 |
137 |
Height |
approx. cm |
89 |
95 |
105 |
138 |
193 |
191 |
197 |
Depth |
approx. cm |
65 |
67 |
80 |
93 |
93 |
105 |
130 |
