Meiji Techno DK3000C - Color Digital CMOS (3.1MP), USB 2.0 Camera

Name: Meiji Techno DK3000C - Color Digital CMOS (3.1MP), USB 2.0 Camera
Brand: Meiji Techno
SKU: MeijiDK3000C
Price: 1800.75 USD
Availability: InStock

0 reviews | Model: Meiji Techno DK3000C

Compare

3.1mp color digital video camera, 1/2 inch CMOS, USB 2.0

DK3000C 3.1mp Color Digital Video Camera, 1/2" CMOS, USB 2.0
Low noise progressive scan ½” 3.1 megapixel CMOS sensor
Full color sub-windowing allows for rapid focus and scanning of samples; up to 80 fps at 640x480 resolution
8 or 10-bit pixel data modes
Software compatible with Windows XP, Windows Vista, Windows 7, and Mac OSX, 32 and 64-bits
Includes TWAIN and DirectX/Direct Show support

View Product Details

List Price: $2,100.00

Your Price: $1,800.75

Sign-in for EDU Pricing!

In Stock:

Free shipping over $99
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded.
View Payment Options

Request Quote

Non-Cancellable / Non-Returnable

Items in This Series



Product	Meiji Techno DK3000C 3.1mp color digital video camera, 1/2 inch CMOS, USB 2.0	Meiji Techno DK1000M 1.3mp monochrome digital video camera, 1/2 inch CMOS, USB 2.0	Meiji Techno DK-LITE-B 1.5mp digital video camera, 1/2.5 inch CMOS, USB 2.0	Meiji Techno DK1000CB 2.0mp color digital video camera, 1/2 inch CMOS, USB 2.0	Meiji Techno DK5000C 5.0mp color digital video camera, 1/2.5 inch CMOS, USB 2.0
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Meiji Techno DK3000C

Low noise progressive scan ½” 3.1 megapixel CMOS sensor
Full color sub-windowing allows for rapid focus and scanning of samples; up to 80 fps at 640x480 resolution
8 or 10-bit pixel data modes
Software compatible with Windows XP, Windows Vista, Windows 7, and Mac OSX, 32 and 64-bits
Includes TWAIN and DirectX/Direct Show support

Color Digital CMOS (3.1MP), USB 2.0 Camera

The DK3000C scientific CMOS camera provides extremely fine detail that was previously invisible to lower megapixel imaging systems with 2048x1536 resolution. Benefit from fast, smooth previews during sample manipulation with high frame rates of up to 80 frames per second.

Recommended Applications:

Brightfield
Darkfield
Live Cell Imaging
Histology
Pathology
Cytology
Defect Analysis
Semiconductor Inspection
Metrology

Meiji Techno Infinity 1 Diagram

Quantum Efficiency Curve

Meiji DK3000C Specification
Camera Sensor
Image Sensor	Micron MT9T001, CMOS, color, progressive scan
Optical Format	1/2"
Active Area	6.5 x 4.9mm
Pixel Size	3.2µm x 3.2µm
Resolution	2048 x 1536 pixels
Region of Interest Control	Any multiple of 8 x 8 pixels, 32 x 32 pixels minimum
Camera Specifications
Frame Rate	12 fps
Bit Depth	8 or 10-bit
Binning / Subsampling Modes	2x subsampling mode
Exposure Control	Manual and automatic control
Exposure Range	128μs to 500ms (video) 128μs to 4s (snapshot)
Gain Control	Manual and automatic control
Gain Range	1 to 3.88x
White Balance	Automatic and manual control
Camera Characteristics
Sensitivity	0.92DN/(nJ/cm2) [at 8-bit, 1x gains]
Dynamic Range	66dB
Full Well Capacity	20,000 e-
Quantum Efficiency	36% (red-peak)
Read Noise	12 e- rms
Dark Current Noise	<8 e-/s
Mechanical Specifications
Data Interface	USB 2.0
Lens Mount	Adjustable C-Mount standard
Dimensions (L x W x H)	3.85 x 2.25 x 2.75 inches
Mass	330g
Operating Temperature	0° C to +50° C
Storage Temperature	-30° C to +70° C
Operating Humidity	5%-95%, Non-condensing
Shock / Vibration	50 G shock, 5 G (2 to 200 Hz) vibration
Camera Software
Operating Systems	Windows XP, Windows Vista, Windows 7, Mac OSX, 32 and 64-bit
Power and Emissions
Power Consumption	~2.5 watts
Power Requirement	USB bus power (optional 6VDC to 500 mA)
Emissions Compliances	FCC Class BE, CE Certified
Hazardous Materials	RoHS, WEEE Compliant
Warranty	One (1) year
System Requirements
Recommended PC Specs	• Pentium 4, 1.3 GHz or higher • 512 MB RAM • 500 MB hard drive free space or more • USB 2.0 Port • Windows 7
Minimum PC Specs	• 600 MHz Processor • 256 MB of SDRAM • 200 MB hard drive free space • USB 2.0 Port • Window XP
Included in the Box
Infinity 1-3C	3.1 MP Digital Camera for USB 2.0
LulNFSW-DVD	DVD with INFINITY user application software (including INFINITY ANALYZE), TWAIN driver and documentation
Lu802	2 m USB 2.0 cable
Model	Version	Image Sensor	Max. Resolution	Video Frame Rate
HD1500T	Color	1/2.8" format 5.7mm x 4.28mm	2MP 1980 x 1080	30 fps @ 1440 x 1080 60fps @ 640 x 480
HD1500TM	Color	1/2.8" format 5.7mm x 4.28mm with 11.8in Monitor	2MP 1980 x 1080	30 fps @ 1440 x 1080 60fps @ 640 x 480
DK-LITE-B	Color	1/2.5" format 5.7mm x 4.28mm	1.5MP 1440 x 1080	15 fps @ 1440 x 1080 60fps @ 640 x 480
DK1000CB	Color	1/2" format 6.5mm x 5.3mm	2.0MP 1600 x 1200	15 fps @ 1600 x 1200
DK1000M	Monochrome	1/2" format 6.5mm x 5.3mm	1.3MP 1280 X 1024	30 fps @ 1280 X 1024
DK3000C	Color	1/2" format 6.5mm x 4.9mm	3.1MP 2048 x 1536	12 fps @ 2048 x 1536 120fps @ 640 x 480
DK5000C	Color	1/2.5" format 5.7mm x 4.28mm	5.0MP 2592 x 1944	5 fps @ 2592 x 1 944 60fps @ 640 x 480
HD2000C	Color	1/3" format 5.2mm x 2.7mm	2.0MP 1920 x 1080	60fps @ 1920 x 1080
ST1000C	Color	1/2.5” format	5.0MP 2592 x 1944	60fps @ 2592 x 1944
