| Capacity x Resolution: |
5 x 0.001 COF*, 2 x 0.0005 lbF, 32 x 0.01 ozF, 1 x 0.0002 kgF, 1000 x 0.2 gF, 10 x 0.002 N |
| Accuracy: |
±0.1% of full scale |
| Sampling rate: |
7,000 Hz |
| Power: |
AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. |
| Battery Life: |
Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use |
| Outputs: |
USB / RS-232: Configurable up to 115,200 baud. Includes Gauge Control Language 2 for full computer control.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VCD, ±0.25% of full scale at capacity,
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines. |
| Configurable Settings: |
COF sled weight, digital filters, outputs, automatic output (via USB/RS-232), automatic shutoff, default settings, averaging mode, external trigger, passwords, key tones, audio alarms, backlight, calibration |
| Safe overload: |
150% of full scale (display shows "OVER" at 110% and above) |
| Weight: |
1.0 lb [0.45 kg] |
| Included items: |
Carrying case with hook, chisel, cone, V-groove, flat, extension rod, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESUR Lite software, MESURTMgauge DEMO software, and user's guide), and NIST-traceable certificate of calibration with data. |
| Warranty: |
3 years (see individual statement for further details) |
