| Capacity x Resolution: |
200 x 0.1 lbF, 3200 x 2 ozF, 100 x 0.05 kgF, 1000 x 0.5 N, 1 x 0.0005 kN |
| Accuracy: |
±0.2% of full scale |
| Wire gauge range*: |
AWG30 - AWG3* |
| Wire diameter range: |
0.03 - 0.25 in [0.8 - 6.3 mm] |
| Minimum sample length: |
7.50 in [191.0 mm], excluding termination |
| Maximum sample elongation: |
1.15 in [29.2 mm] |
| Power: |
AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. |
| Battery Life: |
Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use |
| Sampling rate: |
7,000 Hz |
| Outputs: |
USB / RS-232: Configurable up to 115,200 baud.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible Devices.
Analog: ±1 VCD, ±0.25% of full scale at capacity.
Set points: Three open drain lines. |
| Configurable Settings: |
Digital filters, outputs, break detection, automatic shutoff, default settings, passwords, key tones, audio alarms, backlight, calibration |
| Safe overload: |
150% of full scale (display shows “OVER” at 110% and above) |
| Weight: |
16.0 lb [7.3 kg] |
| Included items: |
Universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESURTMLite software, MESURTMgauge DEMO software, and user's guide), NIST-traceable certificate of calibration |
| Warranty: |
3 years (see individual statement for further details) |
