Now available with an optional digital angle indicator!

The TSTMH Motorized Torque Measurement Test Stand is ideal for a wide variety of torque testing applications up to 100 lbin, including closure torque testing, fastener torque testing, and more. Motorized clockwise and counterclockwise rotation allows for highly precise and repeatable tests. Versatile modular design allows the stand to be configured for a variety of torque sensors and gripping fixtures while a lever-operated slider with travel stops makes engaging and disengaging samples quick and efficient. The stand includes a torque loading plate with tapped holes for grip and custom fixture mounting and a resetable angle indicator.

Available in vertical and horizontal orientations.

Optional equipment

• Series STJ Universal torque sensors
  Mount directly to the TST. A wide range of capacities is available.
• Force/torque gauge
  The BGI displays the torque readout of the STJ sensor
• BGI mounting kit
  For securing the BGI to the column. Height adjustable.
• Digital angle indicator Displays cw or ccw angle in 0.1° resolution for approximately 278 rotations, resettable with "zero" button. Accurate to ±0.7°. Includes backlight. Three sets of mounting holes allow the indicator to be mounted perpendicular to, or parallel to the test stand column. It can also be repositioned along the column. Rugged aluminum housing.
• Jacobs chuck grip
  Universal grip for samples or custom fixtures. Available in capacities of 1/4", 3/8", and 1/2". Mounts to the torque plate.
• Closure grip
  Universal grip for closures up to 4.8" dia.
• Overload protection module
  Protects against accidental overloads during motorized tests. Adjustable from 20 - 110% of the sensor's capacity.
• Set point cable
  Stops test stand rotation at programmable high and low set points for clockwise and counterclockwise torque. Requires the BGI.
• Custom modifications
  Special modifications are available, including custom-designed fixtures, increased column length, and more. Call 1-888-MARK-TEN for more information.

For 220V operation add suffix E to model number. Ex: TSTME

The TSTM / TSTMH is supplied with a wrench set.

Dimensions
