| Accuracy: |
±0.1% of full scale ±1 digit |
| Power: |
AC or rechargeable battery. Multi-step low battery indicator is displayed, gauge shuts off automatically when power is too low. |
| Battery life: |
Backlight on: up to 7 hours of continuous use
Backlight off: up to 24 hours of continuous use |
| Measurement units: |
lbF, ozF, gF, kgF, N, kN, mN (depending on model) |
| Outputs: |
USB / RS-232: Configurable up to 115,200 baud. Includes Gauge Control Language 2 for full computer control.
Mitutoyo (Digimatic): Serial BCD suitable for all Mitutoyo SPC-compatible devices.
Analog: ±1 VCD, ±0.25% of full scale at capacity,
General purpose: Three open drain outputs, one input.
Set points: Three open drain lines. |
| Confi gurable settings: |
Digital filters, outputs, automatic output (via USB/RS-232), automatic shutoff, default settings, averaging mode, external trigger, passwords, key tones, audio alarms, backlight, calibration |
| Safe overload: |
150% of full scale (display shows “OVLD” at 110% and above) |
| Weight (gauge only): |
M5-012 - M5-100: M5-012 - M5-100: 1.0 lb [0.45 kg]
M5-200 - M5-500: 1.2 lb [0.54 kg] |
| Load cell defl ection: |
All models 0.010 [0.25], except 0.050 [0.13] for M5-012 |
| Included items: |
Carrying case with chisel, cone, V-groove, hook, flat, extension rod, universal voltage AC adapter, battery, quick-start guide, USB cable, resource CD (USB driver, MESURgauge DEMO software, and user’s guide), and NIST-traceable certificate of calibration with data. |
| Warranty: |
3 years (see individual statement for further details) |
