Mark-10 ESM001 - Digital Travel Display for ES30
The Mark-10 ESM001 is a Digital Travel Display 6" [150 mm] travel, 0.0005" [0.01 mm] resolution, SPC output for automated data collection. To output data to a PC via USB, use communication adapter part no. MU100 and 09-1066 cable.
Notes:
1. Continuous data output rate is limited to 2 Hz.
2. To output force and travel data to a PC, two USB ports are required, one from the force gauge, and the other from the traveling display via MU100 adapter.
