Logtag UTREL-16 - USB External Probe Low Temperature, USB 2.0-90°C to +40°C, Logger

Name: Logtag UTREL-16 - USB External Probe Low Temperature, USB 2.0-90°C to +40°C, Logger
Brand: Logtag
SKU: LogtagUTREL-16
Price: 55.00 USD
Availability: InStock

0 reviews | Model: Logtag UTREL-16

Compare

USB External Probe Low Temperature, USB 2.0-90°C to +40°C, Logger

Records temperature from -90°C to +40°C.
Display showing temperature and alarm status of up to six alarms.
Cost effective multi-use format with a two year battery life.
Automatic generation of a PDF report as a permanent record of the data.

View Product Details

Your Price: $55.00

In Stock:

Free shipping over $99 - Code: FREESHIP
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded. - USE CODE FREESHIP at checkout

Valid on Web Price Only!
View Payment Options

Request Quote

Items in This Series



Product	Logtag UTREL-16 USB External Probe Low Temperature, USB 2.0-90°C to +40°C, Logge ...	Logtag TREL-8 Multi-Use Low Temperature Remote Probe Logger, 8000 readings, -90°C to +40°C	Logtag TREL30-16 30-Day LCD Display Temperature Logger with an external probe, -90°C to +4 ...	Logtag UTREL-16 Kit UTREL-16 Kit Includes: UTREL-16, ST10M-15Ext Probe, Buffer Kit, Wall M ...	Logtag UTREL-16-NIST Kit UTREL-16-NIST Kit Includes: UTREL-16, ST10M-15Ext Probe, Buffer K ...	Logtag UTREL30-16 Kit-1 UTREL30-16 Kit-1 Includes: UTREL30-16, One ST10M-15Ext Probe, One ...	Logtag UTREL30-WIFI Kit-1 UTREL30-WIFI Kit-1 Includes: UTREL30-Wifi, One ST10M-15Ext Probe ...	Logtag UTREL30-16 Kit-2 30 Day Low-Temperature Logger with Display Kit	Logtag UTREL30-WIFI Kit-2 UTREL30-WIFI Kit-2 Includes: UTREL30-Wifi, Two ST10M-15Ext Probe ...	Logtag UTREL30-16 Dual-channel, Low temperature logger with 30 day temperature display (Pr ...
Price
In Stock
Compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare	Add to compare

Recommended for you

Logtag UTREL-16 Accessories

Choose a Category

for the Logtag UTREL-16

Logtag GLYCOL BUFFER KIT 35ml kit includes bottle, cap, seal glycol not included

Catalog: Gylcol Buffer kit

(0)

In Stock!

Add to Cart

Logtag GLYCOL BUFFER KIT 70ml kit includes bottle, cap, seal glycol not included

Catalog: Glycol Buffer Kit

(0)

In Stock!

Add to Cart

Logtag LTO 1 year Cloud Service LTO 1 year Cloud Service, Single-User

Catalog: LTO 1 YEAR CLOUD SERVICE

(0)

In Stock!

Add to Cart

Logtag LTO 2 year Cloud Service LTO 2 year Cloud Service, Single-User

Catalog: LTO 2 YEAR CLOUD SERVICE

(0)

In Stock!

Add to Cart

Logtag ST100B-15 1.5m cable

Catalog: ST100B-15

(0)

In Stock!

Add to Cart

Logtag ST100H-15 105mm, Tipped, Handle, 1.5m Cable

Catalog: ST100H-15

(0)

In Stock!

Add to Cart

Logtag ST100J-15 40mm tip length, No Handle, 1.5m Cable

Catalog: ST100J-15

(0)

In Stock!

Add to Cart

Logtag ST100J-30 40mm tip length, No Handle, 3.0m Cable

Catalog: ST100J-30

(0)

In Stock!

Add to Cart

Logtag ST100K-15 65mm tip length, No Handle, 1.5m Cable

Catalog: ST100K-15

(0)

In Stock!

Add to Cart

Logtag ST100K-30 65mm tip length, No Handle, 3.0m Cable

Catalog: ST100K-30

(0)

In Stock!

Add to Cart

Logtag ST100L-15 90mm tip length, No Handle, 1.5m Cable

Catalog: ST100L-15

(0)

In Stock!

Add to Cart

Logtag ST100L-30 90mm tip length, No Handle, 3.0m Cable

Catalog: ST100L-30

(0)

In Stock!

Add to Cart

Logtag ST100S-15 30mm, Round Tip, No Handle, 1.5m Cable

Catalog: ST100S-15

(0)

In Stock!

Add to Cart

Logtag ST100S-30 30mm, Round Tip, No Handle, 3.0m Cable

Catalog: ST100S-30

(0)

In Stock!

Add to Cart

Logtag ST100T-15 140mm, Tipped, No Handle, 1.5m Cable

Catalog: ST100T-15

(0)

In Stock!

Add to Cart

Logtag ST100T-30 140mm, Tipped, No Handle, 3.0m Cable

Catalog: ST100T-30

(0)

In Stock!

Add to Cart

Logtag ST10M-15 1.5m Cable

Catalog: ST10M-15

(0)

In Stock!

Add to Cart

Logtag ST10S-05 0.5m Cable

Catalog: ST10S-05

(0)

In Stock!

Add to Cart

Logtag ST10S-15 ST10S-15 (1.5m Cable) 22mm probe length

Catalog: ST10S-15

(0)

In Stock!

Add to Cart

Logtag ST10S-30 3.0m Cable

Catalog: ST10S-30

(0)

In Stock!

Add to Cart

Logtag STX-50 External Sensor Cable Extension

Catalog: STX-50

(0)

In Stock!

Add to Cart

Logtag UTREL-16

Records temperature from -90°C to +40°C.
Display showing temperature and alarm status of up to six alarms.
Cost-effective multi-use format with two-year battery life.
Automatic generation of a PDF report as a permanent record of the data.

Logtag UTREL-16 - USB External Probe Low Temperature, USB 2.0-90°C to +40°C, Logger

The LogTag® UTREL-16 is compatible with the ST10 external probe.

The display shows recording status, current temperature, alarm status of up to six user-configurable alarms, and duration of any temperature excursions.

When the UTREL-16 is connected to a computer using the integrated USB plug, a detailed PDF report of the recorded temperature data and alarms can be automatically generated without the need for extra accessories and proprietary software.

For more detailed data analysis, the UTREL-16 also creates an encrypted data file compatible with LogTag Analyzer® operating software and data management options.

(Silica sand recommended for temperatures below -40ºC for Buffer Assembly)

Buffer bottle & Silica Sand is not included

ST10M-15 external probe is used with Buffer bottle

Product Model	UTREL-16.
Sensor Measurement Range	-90°C to +40°C (-130°F to +104°F).
Operating Temperature Range	-30°C to +60°C (-22°F to +140°F).
Storage Temperature Range	0°C to +40°C (32°F to +104°F).
Rated Temperature Reading Resolution	0.1°C (0.2°F) for measurements -80°C to 10°C (-112°F to 50°F). 0.2°C (0.4°F) for measurements 10°C to 20°C (50°F to 68°F) and -90°C to -80°C (-130°F to -112°F). 0.3°C (0.5°F) for measurements 20°C to 30°C (68°F to 86°F). 0.5°C (0.9°F) for measurements 30°C to 40°C (86°F to 104°F). LogTag Analyzer® currently displays to one decimal place of °C or °F. The native resolution is what is stored in the LogTag®.
Rated Temperature Reading Accuracy	Better than ±0.5°C for -20°C to +10°C (-4°F to 50°F) Better than ±0.7°C for -50°C to -20°C (-58°F to -4°F) and +10°C to +30°C (50°F to 86°F) Better than ±1°C for -80°C to -50°C (-112°F to -58°F ) and +30°C to +40°C (86°F to 104°F) Better than ±1.8°C for -90°C to -80°C (-130°F to -112°F)
Recording Capacity	16,129 temperature readings. 112 days @ 10min logging, 168 days @ 15min logging. Statistics memory (for display on LCD): Max/Min values and alarm duration values.
Sampling Interval	Configurable from 30 seconds to 18 hours.
Logging Start Options	Push button start or specific date & time. Optional start delay.
Alarms	Three configurable upper and three configurable lower alarms.
Recording Indication	“REC” symbol on LCD.
Download Time	Typically with full memory (16,129 readings) in less than 30 seconds from time of insertion to availability of PDF report. Typically less than 10 seconds from time of insertion to availability of LTD file in LogTag® Analyzer (if configured).
Environmental	IP61 (when vertically mounted or hung with USB dust-cap in place).
Power Source	CR2450 3V LiMnO2 (Fixed battery).
Battery Life	1 year storage, 2 years of normal use (based on 15 minute logging, download data monthly).
Real Time Clock	Built-in real time clock. Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day). Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C).
Connection Interface	USB 2.0, A-type plug.
Software	PDF Reader, LogTag® Analyzer 3.1.9 or higher.
PDF Report	One page report with trip and alarm summary. Multi-page report with list of readings, including date and time.
Size	93mm(H) x 54.5mm(W) x 8.6mm(T) including protective USB cap.
Weight	39g.
Case Material	Polycarbonate.

Tech Specs

Dataloggers / Data Acquisition/Dataloggers for Environmental Variables/Temperature Dataloggers Templ
Max Temperature	104 F (40 C)
Min Temperature	-130 F
Power Source	Battery
Battery Life	2 YEARS (17520 HR)
Input Source	External Probe
# Data Points	16129
SAMPLE RATE/Intervals	30 seconds to 18 hours
Accuracy	Better than ±0.5°C for -20°C to +10°C (-4°F to 50°F) Better than ±0.7°C for -50°C to -20°C (-58°F to -4°F) and +10°C to +30°C (50°F to 86°F) Better than ±1°C for -80°C to -50°C (-112°F to -58°F ) and +30°C to +40°C (86°F to 104°F) Better than ±1.8°C for -90°C to -80°C (-130°F to -112°F)
LCD Screen	Yes
Software Included	Yes
Data Output Format	PDF
Test Equipment General Attributes
Interfaces I/O	USB
Storage	Internal Memory
IP Rating	IP61
Product Weight	0.086 LBS
Product Height	3.66 IN
Product Length	0.338 IN
Product Width	2.145 IN
Shipping Weight	0.0989 LBS
Data Logging	Yes
Battery Type	Other
Power Supply Voltage	Battery Powered
