Liberty 24-4P-P-L6SH-BLK Lan/Data Cable

Name: Liberty 24-4P-P-L6SH-BLK Lan/Data Cable
Brand: Liberty
SKU: Liberty24-4P-P-L6SH-BLK
Price: 1174.85 USD
Availability: InStock

0 reviews | UPC: 601446158586 | Model: Liberty 24-4P-P-L6SH-BLK

Compare

Black Category 6 F/UTP EN Series 23 AWG 4 Pair Shielded Cable

23 AWG Solid Bare Copper Conductors
FEP, Fluorinated Ethylene Propylene (Teflon(TM))
Color Striping on white conductors
Varying lay twisted pairs cabled on a common axis
100% Foil shield with foil and drain facing in
Ripcord under the jacket
PL-PVC, Plenum rated Polyvinyl Chloride Alloy Jacket
Third Party (UL, ETL) certified to Category 6 performance
NEC Rated CMP, CEC Rated CMP, CMG FT6, RoHS Compliant
1000 Foot Spools Standard

View Product Details

Sign-in for EDU Pricing!

In Stock:

View Payment Options

List Price: $1,305.38

See Price

Request Quote

Recommended for you

Liberty 24-4P-P-L6SH-BLK Accessories

Choose a Category

Adapter Kits

for the Liberty 24-4P-P-L6SH-BLK

Cal Test CT4103 Universal Adapter Kit

Catalog: CT4103

(9)

In Stock!

Add to Cart

4 pair 23 AWG solid, twisted, and shielded cable NEC type CMP and CEC type CMP FT6. Third party verified to ANSI/TIA-568C Category 6 performance. Product manufactured compliant to the requirements of UL444 for installations and applications in accordance with NEC articles 725 and 800.

Applications:

Plenum Horizontal LAN 10/100/1000BaseT Networking
Balun Infrastructure, Voice, Voice over IP cabling
Video, Audio, InfraRed, IP Control
PoE, HDBaseT, Analog and Digital Multimedia

Conductor	23 AWG Solid annealed bare copper conductors Diameter: 0.0226" \| 0.574mm
Insulation	Fluorinated ethylene propylene Wall thickness: 0.0115" \| 0.2921mm Diameter: 0.045" \| 1.138mm
Color Code	Pair 1: Orange, White/orange stripe Pair 2: Blue, White/blue stripe Pair 3: Green, White/green stripe Pair 4: Brown, White/brown stripe
Assembly	Pairs twisted in varying lay lengths Each pair in a fluoropolymer X separator interstice
Construct	100% Polyester tape binder
Shield	100% aluminum/polyester tape foil in 24 AWG solid tinned copper drain
Jacket	Plenum rated polyvinyl chloride Colors: White, Yellow Wall thickness: 0.023" \| 0.584mm Diameter: 0.290" \| 7.37mm
Electrical
DC resistance	≤ 28.60 Ω / 1000' \| 93.8 Ω/KM
DCR Unbalance	≤ 5.0%
Capacitance	17.0 pF/FT \| 56.0 pF/M
Impedance	100 ± 15 Ω
Propagation Delay (Skew)	45ns/100m MAX
Velocity of Propagation	71%
Voltage rating	300V
Pair to ground capacitance Unbalance	≤ 330 pF/100M
Maximum current	1.4A@25°C
Regulatory	ANSI/TIA-568-C Category 6 NEC: CMP 75°C CEC: CMP FT6 60°C EU RoHS 2002/95/EC Compliant
Packages
Reel	1000' \| 305M
Weight	36 Lbs/1000' \| 54 Kg/KM
Installation
Pull Tension	25 Lbs \| 111 N
Bend radius	2.90" \| 74mm unloaded
Bend radius	5.80" \| 148mm loaded
Plenum cable should be conditioned at room temperature for 24 hours prior to installation and never installed below 32°F \| 0°C ambient temperature
Performance
LAN	300 feet Passive Baluns up to 2500 feet
Final Outside Diameter (inches)	0.290

Tech Specs

Accessories/Cables - Misc Template
Cable Type	Round
Test Equipment General Attributes
Unique Features	23 AWG Solid Bare Copper Conductors FEP, Fluorinated Ethylene Propylene (Teflon(TM)) Color Striping on white conductors Varying lay twisted pairs cabled on a common axis 100% Foil shield with foil and drain facing in Ripcord under the jacket
Safety Approval	RoHS
Product Weight	36 LBS Product Weight Per 1000ft
Country of Origin	United States
