Leica Rugby 410 DG Basic Package, without Accessories

Name: Leica Rugby 410 DG Basic Package, without Accessories
Brand: Leica
SKU: LeicaRugby 410DG - 765666
Price: 3815.00 USD
Availability: InStock

0 reviews | Catalog: 765666 | UPC: 7640110692912 | Model: Leica Rugby 410DG - 765666

Compare

Rugby 410DG, Laser with Carrying Case

Fully automatic, dual grade laser for level, single and dual slope applications
Easy foundation setting thanks to the 5-button keypad
Superior power management for working without interruptions (up to 130 hours)
High-power laser beam provides enhanced distance performance
Full-function long-range two way remote control saves time and reduces communication errors from inside or outside the cab of the machine
Waterproof and dustproof to work reliably in all weather and job site conditions
High-impact composite housing with protective rubber overmolding
Cast aluminum base withstands rough handling and creates a stable platform
Enclosed head for maximum internal component protection
Rugged and reliable, works when you need it

View Product Details

List Price: $3,815.00

In Stock:

View Payment Options

Recommended for you

Leica Rugby 410 DG Basic Package, without Accessories

Leica Rugby 410 DG

Building pads, parking lots and runways
Precise depth control for sub-base and fine grade excavation
Agricultural applications such as land leveling or tiling
Concrete forming and framework
Retention ponds and batters
Setting foundations and footings

The Leica Rugby 410 DG is designed for grading jobs of any size that require the most precise grade control. Ensuring the highest accuracy over long distances, the Leica Rugby 410 DG is perfectly suited for agriculture, machine control and general construction applications. Save on materials and labor with the most accurate grade lasers in the Leica portfolio. When accuracy is the goal, Leica Rugby makes the grade.

The toughest players on big fields

Work reliably and accurately under any weather and jobsite conditions with Leica Rugby 410 DG grade lasers. The high-impact composite housing including the rubber over mold, case aluminum base and enclosed head deliver maximum internal component protection and as a result, assure reliable performance throughout the day.

User-friendly features for precise grade control

The Leica Rugby 410 DG grade lasers offer a wide range of valuable and easy to use features for precise grade control, such as Axis Alignment for higher grade accuracy, Beam Masking for multiple laser usage and Elevation Alert to prevent elevation errors. All these and more can be conveniently accessed and controlled by a 5-button keypad. Save time and reduce communication errors from the field to the cab of the machine by using a long-range two way remote control together with Rugby 410 DG grade lasers. In the development of the Leica Rugby 410 DG, care was taken to ensure absolute compatibility with the widest range of machine control solutions. Invisible IR laser beam of the Rugby 410 DG is the perfect solution for applications where no red light is allowed, like railway maintenance.

Leica Rugby Series Features by Model	Leica Rugby 320 SG	Leica Rugby 410 DG	Leica Rugby 420 DG
Simple to use 5-Button Keypad	✔	✔	✔
Real-Time Grade Matching	✔	✔	✔
Superior Dual Battery Concept	✔	✔	✔
Scope Mount in Both Axes	✔	✔	✔
Laser Beam Visible (Red)	✔	-	✔
Laser Beam Invisible (IR)	-	✔	-
Grade Capability X (or Y) Axis -5 to +25%	✔	✔	✔
Grade Capability in Both Axes -5 to +15%	-	✔	✔
Long Range Remote Control	-	✔	✔
Axis Alignment	-	✔	✔
Laser Plane Stabilization	-	-	✔
Enhanced Operating Range	-	-	✔

Leica Rugby Series Specifications	Leica Rugby 320 SG	Leica Rugby 410 DG	Leica Rugby 420 DG
Operating Range (Diameter)	900m*	800m*	1100m*
Self-Leveling Accuracy	±1.6mm per 30m**
Self-Leveling Range	±5°
Grade Capability	-5 to +25%	-5 to +25% in either axis (-5 to +15% in both axes)	-5 to +25% in either axis (-5 to +15% in both axes)
Grade Resolution	0.001%
Rotating Speeds	5, 10, 15, 20RPS
Laser Diode	635nm visible red laser	780nm invisible (IR)	635nm visible red laser
Size (HxWxD)	265x260x200mm
Weight	5kg without batteries
Operating Temperature	-20° to +50°C
Battery Type	alkaline or NiMH
Battery Life	up to 130hours with alkaline; up to 100hours with rechargeable***
Environmental	watertight to IPX-7 standard
Warranty	2 years factory warranty / additional 3 years on request

*Tested with Leica receivers (CAB Sensor, MLS700, Rod-Eye Digital/Plus) / **Accuracy is defined at +25°C / ***Battery life is dependent upon environmental conditions

Start typing your question...

Answers (1) - Asked by Anonymous

I have this question too (0)

These are packages which contain the Rugby 410 DG, but have a variety of different accessories. The following is a brief overview of what comes with each: • Rugby 410DG - part number 6003520 ? Rugby 410DG, Laser with Carrying Case ? NiMH Battery Pack, Rugby 300-320SG/400-410-420DG ? NiMH Charger, 100-240VAC to 12VDC (excluding AC power cable) ? AC power cable 2-pole US, to charger ? Rugby 410-420DG User Manual English ? Rod Eye-140 Classic Receiver with bracket • Rugby 410DG - part number 6003522 ? Rugby 410DG, Laser with Carrying Case ? NiMH Battery Pack, Rugby 300-320SG/400-410-420DG ? NiMH Charger, 100-240VAC to 12VDC (excluding AC power cable) ? AC power cable 2-pole US, to charger ? User Manual Rugby 320SG ? Rod Eye-160 - Digital Receiver with bracket • Rugby 410DG - part number 6003523 ? Rugby 410DG, Laser with Carrying Case ? RF Remote Control - Rugby 410-420DG (ONLY for use with Rugby 410-420DG) ? NiMH Battery Pack, Rugby 300-320SG/400-410-420DG ? NiMH Charger, 100-240VAC to 12VDC (excluding AC power cable) ? AC power cable 2-pole US, to charger ? User Manual Rugby 320SG ? Rod Eye-160 - Digital Receiver with bracket • Rugby 410DG - part number 6003521 ? Rugby 410DG, Laser with Carrying Case ? RF Remote Control - Rugby 410-420DG (ONLY for use with Rugby 410-420DG) ? NiMH Battery Pack, Rugby 300-320SG/400-410-420DG ? NiMH Charger, 100-240VAC to 12VDC (excluding AC power cable) ? AC power cable 2-pole US, to charger ? Rugby 410-420DG User Manual English ? Rod Eye-140 Classic Receiver with bracket • Rugby 410DG - part number 6003524 ? Rugby 410DG, Laser with Carrying Case ? Alkaline batteries (4D-Cells) ? Rugby 410-420DG User Manual English ? Rod Eye-140 Classic Receiver with bracket • Rugby 410DG - part number 6003526 ? Rugby 410DG, Laser with Carrying Case ? Alkaline batteries (4D-Cells) ? User Manual Rugby 320SG ? Rod Eye-160 - Digital Receiver with bracket • Rugby 410DG - part number 6003525 ? Rugby 410DG, Laser with Carrying Case ? RF Remote Control - Rugby 410-420DG (ONLY for use with Rugby 410-420DG) ? Alkaline batteries (4D-Cells) ? Rugby 410-420DG User Manual English ? Rod Eye-140 Classic Receiver with bracket • Rugby 410DG - part number 6003527 ? Rugby 410DG, Laser with Carrying Case ? RF Remote Control - Rugby 410-420DG (ONLY for use with Rugby 410-420DG) ? Alkaline batteries (4D-Cells) ? User Manual Rugby 320SG ? Rod Eye-160 - Digital Receiver with bracket • Rugby 410DG - part number 765666 ? Rugby 410DG ? Carrying case

I found this helpful (0)

Inaccurate? (0)

Answered by Anonymous
