The automotive software package for the P924xA Keysight Streamline Series USB oscilloscopes enables protocol triggering and decoding for a broad range of the most common automotive serial buses used today for power train and body control and monitoring. This package also enables other advanced analysis capabilities including eye-diagram mask testing and frequency response analysis to help test and debug automotive electronic systems.

• The fastest throughput oscilloscope solution for triggering on and analyzing automotive serial buses using hardware-based architecture.
• On-screen serial decode is time-correlated with the serial data waveform.
• CAN eye-diagram mask testing - easily download multi-region masks and setups based on industry standards.
• Detailed pass / fail statistics from mask tests.
• This package enables CAN, CAN-FD, LIN, SENT, PSI5 (User-definable Manchester), User-definable NRZ, and CXPI serial trigger and decode, along with mask testing and frequency response analysis (Bode plot). Advanced math already comes standard on all P924xA Keysight Streamline Series USB oscilloscopes.
