WaveGen built-in 20 MHz Function/Arbitrary Waveform Generator (option)
The InfiniiVision 3000A X series offers an integrated built-in 20 MHz function/arbitrary waveform generator, available with modulation support (option DSOX3WAVEGEN).
The integrated function generator provides stimulus output of sine, square, ramp, pulse, DC, Sinc (x), exponential rise/fall, cardiac, Gaussian Pulse, and noise waveforms to your device under test. The modulation feature supports AM, FM, and FSK modulations with modulation shapes of sine, square, and ramp. With AWG functionality, you can store the waveforms from analog channels or reference memory to the arbitrary memory and output from WaveGen. Easily create/edit the waveform using the built-in editor or by using Keysight’s Benchlink Waveform Builder Basic.
