Keysight D4000USBB - USB 2.0 Trigger/Decode Software Package for 4000 X-Series Oscilloscopes
The Keysight D4000USBB is the USB 2.0 serial triggering and decoding option for the InfiniiVision 4000 X-series oscilloscopes.
- Enables serial triggering and decode for USB 2.0 low, full and hi-speed (require ≥ 1 GHz bandwidth model), and USB power delivery (USB PD), along with the USB 2.0 signal quality test, mask limit test, and frequency response analysis (Bode plot) capabilities
- Verify the analog quality of signals generated by USB hubs, hosts, and devices based on USB-IF compliance standards
- Trigger on various USB packet types including token, data, handshake, special, as well as various error conditions including PID, CRC, and glitch errors
- Dual-bus decoding with time-interleaved protocol lister / table display
- Serial decode trace time-correlated with USB waveforms
- Compatible with segmented memory acquisition with decoding on every captured packet
- Precision differential probes available
