JBC FAE2-5B - Fume Extractor for Two Workstations (Hoses/Nozzles Sold Separately)

0 reviews | Catalog: FAE2-5B | UPC: 8427327502055 | Model: JBC FAE2-5B

Compare

Fume Extractor - 2 workbenches

Fume extraction system
Nozzles/hoses sold separately
Four flow rates - low, medium, high, custom
Four operation modes - automatic, continuous, pedal, RS-232 control
170 CFM maximum flow rate
0.88 PSI maximum vacuum
54db sound level

View Product Details

List Price: $4,255.00

Your Price: $3,829.50

In Stock:

Free shipping over $99
Please note, FREE SHIPPING is only available on items that can ship via standard ground shipping and is only valid within the Contiguous United States. Any items that must ship via freight or to any destination outside of the Contiguous United States will be excluded.
View Payment Options

Request Quote

Recommended for you

JBC FAE2-5B Accessories

Choose a Category

for the JBC FAE2-5B

JBC FAE2-100 FAE2 H13 + Carbon + M5 Filter

Catalog: FAE2-100

(0)

In Stock!

Add to Cart

JBC FAE2-110 Pre-filter for FAE2 Fume Extractor-Note:Price is for 5 Units

Catalog: FAE2-110

(0)

In Stock!

Add to Cart

JBC FAE010 Flexible Hose Diameter 50 mm

Catalog: FAE010

(0)

In Stock!

Add to Cart

JBC FAE020 Diameter 50 mm Flexible Arm for FAE

Catalog: FAE020

(0)

In Stock!

Add to Cart

JBC FAE030 Accessory for Stand Aspiration

Catalog: FAE030

(0)

In Stock!

Add to Cart

JBC FAE040 Acc. for Stand Aspir. + Clamp

Catalog: FAE040

(0)

In Stock!

Add to Cart

JBC FAE050 Fume Inlet Duct for Mod. Stand

Catalog: FAE050

(0)

In Stock!

Add to Cart

JBC FAE060 Fume Inlet Duct Compact St.

Catalog: FAE060

(0)

In Stock!

Add to Cart

JBC FAE070 Diameter 50 mm Flexible Arm + Clamp

Catalog: FAE070

(0)

In Stock!

Add to Cart

JBC FAE080 Rectangular Nozzle for FAE

Catalog: FAE080

(0)

In Stock!

Add to Cart

JBC FAE081 Round Nozzle for FAE

Catalog: FAE081

(0)

In Stock!

Add to Cart

JBC P-005 Pedal + Adapter Kit

Catalog: P-005

(0)

In Stock!

Add to Cart

JBC FAE2-5B - Fume Extractor (Hoses/Arms Sold Separately)

The JBC FAE2-5B is a versatile, multi-port fume extraction system, offering users a high level of control and functionality. The FAE2-5B can be set up in several different configurations with multiple compatible hose and nozzles styles. Please note, hoses and nozzles are sold separately.

High level of control

The FAE2-5B enables users to customize the machine to their specific application. It is capable of four different flow rates - low, medium, high and custom.

It also offers four operation modes:

Automatic - the FAE2-5B will turn on and off automatically as soldering starts and stops. Certain stations will also require the QSC-A
Continuous - the machine is turned on and operates until it is turned off
Pedal - users can control the machine with a P-005 foot pedal
RS-232 remote control

Can be used in many configurations

The JBC FAE2-5B can be set up in a variety of different manners and is compatible with several different styles of fume extraction hoses. Please note, hoses and nozzles are sold separately.

The image below shows the different ways it is possible to configure the FAE2-5B. You can click on each part number for more information about that specific item.

Ø 50 mm Flexible Arm (Ref. FAE020 or FAE070) Ref. FAE020 Completely flexible arm to be adjusted to your workbench (hole drilling required). Length: 0,94 m - 37 in (compressed). Ref. FAE070 Flexible arm + clamp to fix it to the table. Length: 0,94 m - 37 in (compressed). Ø 50 mm Flexible Hose Ref. FAE010 Connect the Fume Extractor to Flexible Arm. Length: 1,5 m - 59 in (unfolded). Fume Extractor Ref. FAE2-5A Stations with only a USB-B communication port require a QSC controller in order to be connected to FAE fume extractors. See more detailed information in the next link: QSC-A*		Accessory for Stand Aspiration (Ref. FAE030 or FAE040) Ref. FAE030 Accessory for stand aspiration. Connect up to 4 stands (hole drilling required). Ref. FAE040 Accessory for stand aspiration (up to 4 stands) + clamp to fix it to the table. Stand Aspiration Ducts (Ref. FAE050 or FAE060) Ref. FAE050 Fume Inlet Duct for Modular Stands (SD version) Connect the Accessory for stand aspiration to stands. Length: 106 mm (4.17 in). Ref. FAE060 Fume Inlet Duct for Compact stations. Connect the Accessory for stand aspiration to Compact stations. Length: 106 mm (4.17 in).

Specifications
Selectable parameters
Aspiration flow rate	Low/Medium/High/Custom
Operation modes	Automatic (JBC Stations) Continuous Pedal RS-232 remote control
Others
Blower type	Brushless
Max. flow rate	290m3/h (170.7 CFM)
Max. vacuum	6.1 KPa (0.88 psi)
Work areas	2
Noise Level	54 dB @ 1m
Filters
Pre-filter	Medium dust filter M5 (EN 779)
Compact filters	H13 particle filter (EN 1822) + activated carbon filter
Connectivity
USB-B	Firmware update/QSC connection
Station 1-2 (RJ12)	Direct connection for 2 Stations
Robot (RJ12)	RS-232 remote control
Aux (RJ45)	Peripheral expansion
Pedal	Optional tool control through Pedal P-005
ESD/EOS
ESD safe
Power supply
Peak power	400 W (120 V - 230 V) 320 W (120 V)
Voltage (AC)	ref. FAE2-5A: 100 - 240 V
Ambient operating temp.	10 to 40 °C / 50 to 104 °F
Dimensions and weight
Unit	558 x 292 x 562 mm / 33.6 kg 22.0 x 11.5 x 22.1 in / 74.08 lb
Package	615 x 368 x 637 mm / 36.0 kg 24.2 x 14.5 x 25.1 in / 79.4 lb

Tech Specs

Test Equipment General Attributes
HTS/Schedule B Number	85086000
Country of Origin	Spain
