Frequency Range (For Sine, Square): 1Hz ~ 20MHz Frequency Range (For Triangle): 0.1Hz ~ 1MHz Resolution: 1Hz Stability: ? 20ppm Accuracy: ? 20ppm Aging: ? 5ppm / year Output Function: Sine, Square, Triangle Amplitude Range: 10Vpp (into 50O load) Flatness (Sine wave relative to 1kHz): ?0.3dB, 0.1Hz~1MHz; ?0.5dB, 1MHz~4 MHz; ? 2dB, 4MHz~10MHz /td? Impedance: 50O ? 10% Attenuator: -20dB ? 1dB x 2 DC Offset: -5V ~ +5V (into 50O load) Duty Control Range: 20% to 80% below 1MHz (Square wave only) Resolution: 1% Display: 9 digits LED display Harmonics Distortion: -55dBc, 0.1Hz~200kHz; -40dBc, 0.2MHz~4MHz; -30dBc, 4MHz~10MHz(Specification applied from MAX. to 1/10 level) Linear: =98%, 0.1Hz~100kHz; =95%, 0.1Hz~1MHz Symmetry: ?1% period +4ns to 0.1Hz~100Hz; Rise or Fall Time=25ns at maximum output. (into 50O load) Level: 4Vpp?1Vpp~ 14.5Vpp?0.5Vpp adjustable; Rise or Fall Time; =120ns Level: =3Vpp; Fan Out; 20 TTL load; Rise or Fall Time; =25ns Size: 10 groups of Setting memories |
