Instek GWF-202 Wow & Flutter Meter

Name: Instek GWF-202 Wow & Flutter Meter
Brand: Instek
SKU: InstekGWF-202
Price: 844.77 USD
Availability: InStock

0 reviews | Model: Instek GWF-202

Compare

Wow & Flutter Meter

Input level from 5mV ~ 10Vrms

0.005% ~ 3% Measuring range

JIS, NAB, CCIR, DIN, Standard

Center Frequency 3kHz, 3.15kHz

Built-in digital counter

View Product Details

List Price: $969.00

In Stock:

Recommended for you

Choose a Category

(9)

In Stock!

Add to Cart

Center Frequency	3kHz + 200Hz (CCIR, NAB, JIS), 3.15kHz + 200Hz (DIN)
Input Level	5mV ~ 10Vrms
Input Impedance	330kΩ + 20% at 3kHz and 3.15kHz
Range	0.1, 0.3, 1, 3% full scale in 4 ranges
Meter Accuracy	Within + 5% of full scale deflection
Indication	RMS indication (based on JIS standard), Average responding (based on NAB standard), Peak value indication (based on CCIR, DIN standard)
Mode	WTD, WOW, FLUTTER, LIN

Tape Speed
Display	4 digits with 7 segment LED's
Range	2.700kHz ~ 3.500kHz

Frequency Counter
Frequency Range	10Hz ~ 999.9kHz
Accuracy	Timebase accuracy +1 count
Time Base	2.016 MHz crystal oscillator, temperature characteristics, + 5 x 10^-5
Display	4 digits with 7 segment LED's
Input Level	50mV ~ 10Vrms

Signal Source
Oscillators Frequency	3kHz and 3.15kHz
Accuracy	+ 5 x 10^-5

Output	Output of drift and outputs for oscilloscope and recorder

Power Source	AC 100/120/220/240V ±10%, 50/60Hz

Accessories	Power cord x 1, Instruction manual x 1, Test Lead GTL-103 x 1

Dimensions & Weight	310(W) × 110(H) × 395(D) mm, Approx. 6kg
