Item | Specification |
| Frequency | Range | 9kHz-2.7GHz |
| Accuracy | see time base |
| Span Accuracy | see time base |
| SpanRange | 2kHz to 2.5GHz in 1/2/5sequence, full span, zero span |
| Phase Noise | -85dBc/Hz @1GHz 20kHz Offset typical |
| Time Base | ± 10ppm, 0-50C, 1ppm/yr |
| Bandwidth | RBW Selections | 3kHz, 30kHz, 300kHz, 4MHz, |
| RBW Accuracy | 15% |
| Video Bandwidth | 10Hz to 1MHz in 1-3 steps |
| Sweep time | 100 ms to 25.6 s |
| Amplitude | Input Range | -105dBm to +20dBm 10M to 2.5GHz
-100dBm to +20dBm 2.5GHzm to 2.7GHz |
| Reference Level Range | -30 to +20dBm, overload protected |
| Accuracy | ± 1.5dB @100MHz |
| Frequency Flatness | ±1.5dB, |
| Display Range Linearity | ± 1.5dB over 70dB |
| Overload protection | +30dBm, ±25VDC |
| Average Noise Floor | -140dBm/Hz 10MHz to 2.5GHz
-135dBm/Hz 2.5GHz to 2.7GHz |
| Harmonic Distortion | <-40dBc, RF Input <Selected Reference Level |
| Non-harmonic Spurious | <-60dB, Down from Reference Level |
| Third Intermodulation | <-70dBc @-40dBm Input |
| Trace Detection: | Peak, Average |
| Input | RF input Overload Protection | +30dBm Continuous |
| Impedance: | 50 Ohm nominal |
| Return loss | <1.5:1 @10M to 2.5GHz, 0dBm
<2:1 @2.5GHz to 2.7GHz, 0dBm |
| Connector | Type N Female |
| External reference clock inputFrequency | 64k, 1M, 1.544M, 2.048M, 5M, 10M, 10.24M, 13M, 15.36M, 15.4M, 19.2M |
| Others | Internal Memory | 100 traces or Setup |
| Power measurement | ACPR, OCBW, Channel power |
| Reference clock output | 10MHz |
| General | Display: | 640 x 480 high resolution graphical LCD, B&W |
| Interfaces: | RS232C, |
| Features | Trace memory and math, Marker search functions, |
| Weight: | 4.5kg, |
| Size | 330 (W) x 170(H) x 340(D) mm |
| Certification | CE, Installation category II, pollution degree 2 |
