Instek GPS-4251 Multi-Output Series DC Power Supply

Name: Instek GPS-4251 Multi-Output Series DC Power Supply
Brand: Instek
SKU: InstekGPS-4251
Price: 357.44 USD
Availability: InStock

0 reviews | Model: Instek GPS-4251

Compare

DC Power Supply - 0-25Vx2,0-0.5Ax2;3-6V,2.5A fixed;8-15V,1A fixed

Quad Independent DC Output
Four LED Display with 3 digits, selectable for two sets output voltage and current display simultaneously
Auto Series, Parallel and Tracking Operation
Constant Voltage and Constant Current Operation
Low Ripple and Noise
Overload and Reverse Polarity Protection
Selectable for Continuous/Dynamic Load
Output Enable/Disable Control
Rotation speed of the fan is controlled by heatsink temperature
Jack Type Terminal for Europe (Option)

View Product Details

List Price: $410.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Power Supply Kits

for the Instek GPS-4251

Cal Test CT4041 Power Supply Accessory Kit ( rated for up to 20amps ) Get the most...

Catalog: CT4041

(24)

In Stock!

Add to Cart

Specifications

Output

	Voltage	Current	Tracking Series Voltage	Tracking Parallel Current
Ch 1	0 ~ 25V	0 ~ 0.5A	0 ~ 50V	0 ~ 1A
Ch 2	0 ~ 25V	0 ~ 0.5A	0 ~ 50V	0 ~ 1A
Ch 3	3~6V	2.5A Fixed	-	-
Ch 4	8~15V	1A Max.	-	-

Constant Voltage Operation (Ch1, Ch2)

Line Regulation	≤ 0.01% + 3mV
Load Regulation	≤ 0.01% + 3mV (rating current ≤ 3A) ≤ 0.02% + 5mV (rating current > 3A)
Ripple & Noise	≤ 1mVrms 5Hz ~ 1MHz
Recovery Time	≤ 100µS (50% Load change, Minimum load 0.5A)

Constant Current Operation (Ch1, Ch2)

Line Regulation	≤ 0.2% + 3mA
Load Regulation	≤ 0.2% + 3mA
Ripple & Noise	≤ 3mArms

Tracking Operation (Ch1, Ch2)

Tracking Error	≤ 0.5% + 10mV of the Master
Series Regulation	≤ 300mV
Load Regulation	≤ 0.01% + 3mV
Ripple & Noise	≤ 2mVrms 5Hz ~ 1MHz
