Instek GPR-6030D 0-60V, 0-3A Digital Power Supply

Name: Instek GPR-6030D 0-60V, 0-3A Digital Power Supply
Brand: Instek
SKU: InstekGPR-6030D
Price: 324.00 USD
Availability: InStock
Rating: 5.00 (1 reviews)

5 (1 Review) | Model: Instek GPR-6030D

Compare

180W DC Linear Power Supply 0-60V, 0-3A DIGITAL

0-60V, 0-3A
0.01% High Regulation
Constant Voltage and Constant Current Operation
Internal Select for Continuous or Dynamic Load
Low Ripple and Noise
Overload and Reverse Polarity Protection
3 1/2 Digit 0.5" LED Display

View Product Details

List Price: $360.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Power Supply Kits

for the Instek GPR-6030D

Cal Test CT4041 Power Supply Accessory Kit ( rated for up to 20amps ) Get the most...

Catalog: CT4041

(24)

In Stock!

Add to Cart

0-60V, 0-3A DIGITAL

The GPR-M Series are single output, 180W, linear DC power supplies, featuring all the same functions as the GPR-H Series but for lower power demands. Like the GPR-H Series, the GPR-M Series are suitable for high-end precision bench top applications. Low load and line regulation for both constant voltage and constant current mode ensure reliable, predictable output. Overload and reverse polarity protection as well as internal selection for dynamic or constant load are standard.

	GPR-1810HD	GPR-3060D	GPR-6030D
DC OUTPUT
Output Volts (V)	0 ~ 18	0 ~ 30	0 ~ 60
Output Amps (A)	0 ~ 10	0 ~ 6	0 ~ 3
CONSTANT VOLTAGE OPERATION
Regulation	Line regulation≤0.01% + 3mV Load regulation≤0.01% + 5mV (<10A) Load regulation≤0.02% + 5mV (>10A)
Ripple & Noise	≤1mVrms (5Hz ~ 1MHz)
Recovery Time	≤100µS ( 50% load change, minimum load 0.5A )
Output range	0 to rating voltage continuously adjustable
CONSTANT CURRENT OPERATION
Regulation	Line regulation≤0.2% + 3mA Load regulation≤0.2% + 3mA
Ripple Current	≤3mArms
Output Range	0 to rating current continuously adjustable
METER
Type	3 1/2 Digit 0.5" LED Display
Accuracy	±( 0.5% of rdg + 2 digits )
INSULATION
Chassis and Terminal	20MΥ or above (DC 5000V)
Chassis and AC Cord	30MΩ or above (DC 500V)
POWER SOURCE
	AC 100V/120V/220V/240V±10%, 50/60Hz
ACCESSORIES
	User manual x 1 Power cord x 1 Test lead GTL-105 x 1 GTL-104 x 1
DIMENSIONS & WEIGHT
	255(W) x 145(H) x 335(D)mm Approx. 11.5kg

Tech Specs

Power Supplies/DC Power Supplies Template
Outputs	Single
Voltage Output 1	Variable
Max Voltage Output 1	60 V
Programmable	No
Current Output 1	Variable
Max Current Output 1	3 A
Meter Type	Digital
Switching	No
Linear/Switching	Linear
Constant current/voltage	Yes
Test Equipment General Attributes
Unique Features	Internal Select for Continuous or Dynamic Load Low Ripple and Noise Overload and Reverse Polarity Protection
Product Weight	11.5 KILOS (25.35 LBS)
Product Height	335 MM (13.19 IN)
Product Length	255 MM (10.04 IN)
Product Width	145 MM (5.71 IN)
Data Logging	No
ECCN Number	EAR99
Power Supply Voltage	120V/220V Universal
Country of Origin	China
Shipping Height	9.75 IN
Shipping Length	14.25 IN
Shipping Width	18.00 IN
