Instek GPC-3060 0-30V, 0-6A Triple Output

Name: Instek GPC-3060 0-30V, 0-6A Triple Output
Brand: Instek
SKU: InstekGPC-3060
Availability: InStock

0 reviews | Model: Instek GPC-3060

Compare

0-30V, 0-6A triple output

Dual Adjustable Output plus 5V 3A Fixed Output
Auto Tracking
Auto Series and Parallel Operation
Constant Voltage and Constant Current Operation
Low Ripple and Noise
Internal Select for Continuous or Dynamic Load
Overload and Reverse Polarity Protection
Four Analogue Meters for Voltage and Current Readings

Model	Independent	Series	Parallel
GPC-3060	0 ~ 30V x 2 0 ~ 6A x 2	60V 6A	30V 12A

The GPC-SERIES HIGH OUTPUT have dual adjustable outputs plus a single 5V 3A fixed output.
The dual adjustable outputs can be operated independently, in series, or in parallel.

View Product Details

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Power Supply Kits

for the Instek GPC-3060

Cal Test CT4041 Power Supply Accessory Kit ( rated for up to 20amps ) Get the most...

Catalog: CT4041

(24)

In Stock!

Add to Cart

Operation Mode	Independent:	Two independent outputs and 5V fixed output Outputs from 0V to rated voltage and 0A to rated current
	Series:	Output from 0V to ± rated voltage at rated current Output from 0V to double rated voltage at rated current
	Parallel:	Output from 0A to double rated current at rated voltage
5V Fixed Output	Line Regulation:	£5mV
	Load Regulation:	£10mV
	Ripple and Noise:	£2mVrms
	Voltage Accuracy:	5V ±0.25V
	Output Current:	3A
Tracking Operation	Tracking Error:	£0.5% + 10mV of the master
Tracking Operation	Series Regulation:	£300mV
Constant Voltage Operation	Line Regulation:	£0.01% +3mV
	Load Regulation:	£0.01% +5mV (rating current <10A) £0.02% +5mV (rating current ³10A)
	Ripple and Noise:	£1mVrms 5Hz ~ 1MHz
	Recovery Time:	£100µs (50% load change, minimum load 0.5A)
Constant Current Operation	Line Regulation:	£0.2% +3mA
	Load Regulation:	£0.2% +3mA
	Ripple Current:	£3mArms
Meter	Meter Type:	Two each analogue voltmeter and analogue ammeter 2.5 class
Meter	Meter Size:	Each meter 50mm x 50mm
Insulation	Chassis and Terminal:	100MW or above (1000V DC)
Insulation	Chassis and AC Cord:	100MW or above (1000V DC)
Other Details	Power Source:	AC 100V/120V/220V/240V ±10%, 50/60Hz
	Accessories:	Power cord x 1, Instruction manual x 1, Test lead (type GTL-105, type GTL-104 with GPC-3060) x 3
	Dimensions:	255mm (w) x 145mm (h) x 420mm (d)
	Weight:	18.5kg
