Instek GOM-801G Component Tester

Name: Instek GOM-801G Component Tester
Brand: Instek
SKU: InstekGOM-801G
Price: 278.97 USD
Availability: InStock

0 reviews | Model: Instek GOM-801G

Compare

DC Milli-Ohm Meter 20mOhm~20kOhm

Measures from 20mW ~ 20kW in 7 ranges

1A High Test Current

High Resolution 10µW

Hi/Lo Comparator Indicator

3 1/2 Digits 0.5" LED Display

View Product Details

List Price: $320.00

In Stock:

Recommended for you

Test Range	20mΩ, 200mΩ, 2Ω, 20Ω, 200Ω, 2kΩ 20kΩ 7 ranges

Accuracy	Measuring 20mΩ+ (0.2% rdg + 6 digits), 200mΩ~ 20kΩ+ (0.2% rdg + 4 digits), Setting + (0.2% + 6 digits)

Resolution	0.01, 0.1 , 1, 10, 100mΩ, 1, 10Ω

Comparator	HI, LO setable

Display	3 1/2 digits 0.5" LED display;HI, GO, LO indicator

Power Source	AC 115V/230V±10%, 50/60Hz

Accessories	Test lead GTL-108 × 1, Instruction manual × 1

Dimensions & Weight	230(W)×95(H)×280(D) mm, Approx. 2kg
The instrument is specially designed for simplicity in measuring the contact resistance of switch, relay, plug, connector, or between electrolytic lead leg and electrode. All the low resistance can be measured.
