Output Waveforms: Sine, Square, Triangle, ?Ramp, Pulse, AM, FM, Sweep, Trigger, Gate, Burst Frequency Range: 10mHz~15MHz in 8 Frequency Range (auto switch) Frequency Resolution: 15MHz~150kHz(100Hz);1.5MHz~15kHz(10Hz); 150kHz~1.5kHz(1Hz);15kHz~150Hz(0.1Hz);1.5kHz~15Hz(10mHz); 150Hz~1.5Hz(10mHz);15Hz~0.15Hz(10mHz); 1.5Hz~0.01Hz(10mH) Frequency Accuracy: 0.02% + 5 count Output Impedance: 50O ?10% Amplitude Range: 10.00V~0.01V(into 50O ) 4 amplitude ; |Vac peak|+|Vdc|=5V Resolution: 10mV (10.00V~0.01V) Amplitude Accuracy: =3%? 5 count at 10Hz~1MHz ; =10%?5count at 1MHz~15MHz Amplitude Unit: Vpp, Vrms, dBm DC Offset: -5V~+5V(into 50O ) ; Resolution 10mV DC Offset Accuracy: =3%? 3 count at amplitude min. Duty Control: 80%:20%:80% to 1MHz ; Resolution 1% Duty Accuracy: =1% ~ 1MHz at 50% duty Display: Dual Display for Frequency 6 digits and Amplitude 4 digits Distortion: = 0.5%(-46dB) THD from 10Hz to 100kHz; =-30dBc to 15MHz (spec. applied form 1Vpp~10Vpp) Linear Error: 1% of full scale output at 100Hz Asymmetry: ?1% of period + 3ns Rise or Fall Time: 18nS Impedance: 50O?10% Level: 1Vpp open circuit Types: AM, FM, Sweep, Trigger(int/ext), Gate or Burst (implement by trigger type) Waveform: Sine, square, triangle, ramp or Variable Symmetry Pulse Rate Frequency Range: 10mHz~10kHz in 3 Frequency Range (auto switch) Rate Frequency Accuracy: 5% ?1 count Rate Frequency Resolution: 10.0kHz~0.1kHz(100Hz); 99Hz~1Hz(0.1Hz); 0.99Hz~0.01Hz(0.01Hz) Symmetry: 90%:10%:90% ; Resolution1% Symmetry Accuracy: ?1 count (=?1%) Output Level: ?1Vp-p into 10KO load Sine Wave Distortion: =1% from 10Hz to 10kHz Depth: 0~100% Modulation Frequency Rate: 0.01Hz~10kHz(INT) DC~1MHz(EXT) Carries ?3dB Bandwidth: 100Hz to 5MHz External Sensitivity: =10Vp-p for 100% modulation Deviation: 0 ~ ?5% Modulation Frequency Rate: 0.01Hz~10kHz(INT) DC~50kHz(EXT) External Sensitivity: =5Vpp for 15% deviation Sweep Range: 15MHz~150kHz ; 1.5MHz~15kHz ; 150kHz~1.5kHz ; 15kHz~150Hz ; 1.5kHz~15Hz ; 150Hz~1.5Hz ; 15Hz~0.15Hz ; 1.5Hz~0.01Hz Width: 100:1 (in same frequency range) Rate: 0.01Hz~10kHz Symmetry Control: 90%:10%:90% ; Resolution1% Mode: Linear / Log sweep Sweep output: 0 to ?-5Vp-p into 10KO Start/Stop Phase Range: 80?~90? Rate: 0.1Hz~10kHz Frequency Range: 0.1Hz~1MHz(Useful to 10MHz) Ext TRIG Frequency Range: DC to 1MHz,TTL compatible input level Gate or Burst: Implement by trigger setting Range: 100:1(0 to 10V?1) Input Linearity: 0.5% to 1MHz,5% to 10MHz Input Impedance: 10kO GCV Output: To set the voltage between 0.2V to 2V as per different Frequency INT/EXT: Switch Selector Range: 5Hz~150MHz EXT Accuracy: Time base accuracy ?1count Time Base: ?20ppm(23??5?) after 30 minutes warm up Resolution: The maximum resolution is 100nHz for 1Hz and 0.1Hz for 100MHz Input Impedance: 1MO // 150pF Sensitivity: =35Vrms(5~100MHz);=45Vrms(100MHz~150MHz) |
