Instek GDS-2102 Series 100MHz Digital Storage Oscilloscope 2 Channel

Name: Instek GDS-2102 Series 100MHz Digital Storage Oscilloscope 2 Channel
Brand: Instek
SKU: InstekGDS-2102
Price: 1128.97 USD
Availability: InStock

0 reviews | Model: Instek GDS-2102

Compare

Digital Osilloscope - 100MHz; 1GS/s; 2 Ch. with RS-232; USB.

Free 128 MB USB Storage Device
Free Remote Control Software ( program the unit, download data, download images, etc )
100MHz bandwidth
2 channels
1GS/s Real-Time and 25GS/s equivalent-Time Sampling
25K Points Record Length Maximum
Large 5.6-in TFT Color Display
USB Host/Device: Support USB Printer and USB Flash disk. Use a USB thumb drive to store data, images, settings, and even do firmware updates via the USB.
Up to 24 Automatic Measurements
Video/Pulse Width/Event-Delay/Time-Delay Trigger
FFT Analysis
Up to 8ns Peak Detection
Program Mode and Go-No Go Function
RS-232 and GPIB Interface
Multi-Language and Build-in On-Line Help
A Large 8 12 Divisions Waveform Display
Ultra-bright color TFT display - Wide-angle viewable area
Store waveform raw data (CSV files)
Capture screen image as BMP files
Print waveform via USB printer
Better Performance - Faster Sampling Rate, Longer Memory & Advanced Trigger
More Features - Auto Frequency Counter, Auto Setup Sequence, GO/NO GO, 12 Div Display, Simultaneous Cursors
More Value Added Features - RS-232C (Std.), USB Host/Device (Std.), GPIB IEEE 488.2 (Opt.), Free Software
Valued Plus Features - Real Time Frequency, Counter, Auto Setup Sequence, Multi-Language, Built-in Help Menu

View Product Details

List Price: $1,295.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

for the Instek GDS-2102

Cal Test CT4103 Universal Adapter Kit

Catalog: CT4103

(9)

In Stock!

Add to Cart

Instek GTL-232 RS-232 Cable, 9-Pin, F-F Type, Null Modem, 2000mm

Catalog: GTL-232

(0)

In Stock!

Add to Cart

Rigol ADP0150BNC 50 Ohm impedance adapter for oscilloscopes or generators

Catalog: ADP0150BNC

(30)

In Stock!

Add to Cart

Cal Test CT4042 Oscilloscope Accessory Kit. Get the most out of your scope with this...

Catalog: CT4042

(24)

In Stock!

Add to Cart

Aim-TTi Iprober 520 Positional Current/Field Probe DC-5MHz 5mA-20A

Catalog: 58250-0010

(5)

In Stock!

Add to Cart

Auburn P-20A 3GHz RF Probe BNC. (adaptor for SMA not included )

Catalog: P-20A

(3)

In Stock!

Add to Cart

The GDS-2000 Series Digital Storage Oscilloscopes feature a bandwidth of 60, 100 or 200MHz. These 2 or 4 channel instruments deliver a sample rate of 1G Samples/s and a maximum record length of 25K Samples. The scopes can be programmed to take up to 24 different measurements automatically and results can be displayed on the large 5.6 inch color TFT display. A Go/ No Go mode is particularly useful in a production set-up. USB host and device interfaces are provided as standard, with GPIB as an option.

USB Host/Device: Support USB Printer and USB Flash disk. Use a USB thumb drive to store data, images, settings, and even do firmware updates via the USB.

Go/No Go Output


Go/No Go Function	Ideal Data Set	Define Acceptable Range	Automated Pass/Fail

Valued Plus Features


Valued Plus Features	Multi-Language Support	Real Time Frequency Counter	Easy to Use Auto Setup Sequence

Adjustable Probe Compensation Signal / 12 Division Horizontal Display


Adjustable Probe Compensation Signal	Frequency Range: 1kHz~100kHz	Duty Cycle: 5%~95%	12 Division Horizontal Display

Measurement Functions


Measurement Functions	Up to 24 Automatic Measurement Functions

FFT / Cursor Measurement


Fast Fourier Transfer	Built-in FFT as standard Easily switch from time to frequency domain!	Simultaneous Horizontal (V) and Vertical (T) Cursors

Software / Data Exchange


Software/USB Support	Data Exchange

Model	GDS2062	GDS2064	GDS2102	GDS2104	GDS2202	GDS2204
Bandwidth	60MHz	60MHz	100MHz	100MHz	200MHz	200MHz
Channels	2	4	2	4	2	4
Sample Rate	1.0 GS/s
Record Length	25k samples maximum
Display	5.6 Color TFT LCD
USB Host/Device RS232/Go-NoGo	Standard
GPIB Battery	Option
Display	TFT Color
Viewing Angle	Up to +/- 45 deg.
Advanced Trigger	Auto-Level Trigger Event-Delay Trigger Time-Delay Trigger Pulse-Width Trigger TV-Line Trigger
Measurement Functions	Up to 24 Automatic Measurement Functions: Vhi, Vlo, Vmax, Vmin, Vp-p, Vavg, Vrms, Vamp, Rise Time , Fall Time, Width+ , Width-, Period , Duty cycle, Frequency, Delay
FFT (Fast Fourier Transfer)	Built-in FFT as standard Enable user to switch from time domain to frequency domain! Useful math function for school education
Cursor Measurement	Simultaneous Horizontal Cursors ΔV and Vertical Cursors ΔT
Adjustable Probe Compensation Signal	Frequency Range: 1kHz~100kHz Duty Cycle: 5%~95%
USB Host/Device Interface	USB 1.1 & 2.0 device & host supported
Software Support	Real time Video display on PC Monitor through USB. Captured Waveform Data transferred to PC through USB/RS-232C/GPIB. LabView Driver
Warranty	Limited Lifetime

Tech Specs

Oscilloscopes/Digital Oscilloscopes Template
Bandwidth	100 MHz
Channels	2
Sampling Rate	1 GS/S
Memory	25 kB
Rise Time	3.5 ns
Screen Size	5.6 IN
Bits	8
Test Equipment General Attributes
Unique Features	USB Host/Device: Support USB Printer and USB Flash disk. Use a USB thumb drive to store data, images, settings, and even do firmware updates via the USB.
Warranty	1 LIMITED LIFETIME (1 YEARS)
Interfaces I/O	GPIB, RS-232, USB Host, USB Interfaces I/O *GPIB is an option
Product Weight	4.3 KILOS (9.48 LBS)
Product Height	254 MM (10 IN)
Product Length	310 MM (12.20 IN)
Product Width	142 MM (5.59 IN)
Data Logging	Yes
Power Supply Voltage	120V/220V Universal
Country of Origin	Taiwan
