Channels: 2

Bandwidth: DC~100MHz(-3dB)

Rise Time: 3.5ns Approx.

Sensitivity: 2mV/div ~ 10V/div (1-2-5 increments)

Accuracy: ±(3% x |Readout|+0.1 div + 1mV)

Input Coupling: AC, DC & Ground

Input Impedance: 1M±2%, ~16pF

Polarity: Normal & Invert

Maximum Input: 300V (DC+AC peak), CATII

Waveform Signal Process: + , - , x, FFT

Offset Range: 2mV/div ~ 50mV/div : ±0.4V 100mV/div ~ 500mV/div : ±4V 1V/div ~ 5V/div : ±40V

Bandwidth Limit: 20MHz (-3dB)

Sources: CH1 , CH2 , Line , EXT

Modes: Auto, Normal, Single, TV, Edge, Pulse Width

Coupling: AC , DC , LF rej. , HF rej. , Noise rej.

Sensitivity: DC ~ 25MHz: Approx. 0.5div or 5mV;25MHz ~ 100MHz: Approx. 1.5div or 15mV

Range: ±15V

Sensitivity: DC ~ 30MHz : ~ 50mV ; 30M ~ 60MHz : ~100mV

Input Impedance: 1MO?2% , ~ 15pF

Maximum Input: 300V (DC AC peak) , CATII

Range: 1ns/div ~ 10s/div (1-2.5-5 increments); ROLL : 250ms/div ~ 10s/div

Modes: Main, Window, Window Zoom, Roll, X-Y

Accuracy: ±0.01%

Pre-Trigger: 10 div maximum

Post-Trigger: 1000 div

X-Axis Input: Channel 1

Y-Axis Input: Channel 2

Phase Shift: ±3° at 100kHz

Real-Time Sample Rate: 250MSa/s maximum

Equivalent Sample Rate: 25GSa/s maximum

Vertical Resolution: 8 Bits2Mega Points maximum

Acquisition Mode: Normal, Peak Detect, Average

Peak Detection: 10ns (500ns/div ~ 10s/div)

Average <</td>: 2 , 4 , 8 , 16 , 32 , 64 , 128 , 256

Voltage Measurement: Vpp ,Vamp ,Vavg ,Vrms ,Vhi ,Vlo ,Vmax ,Vmin ,Rise Preshoot/Overshoot,Fall Preshoot/Overshoot

Time Measurement: Freq ,Period ,Rise Time ,Fall Time ,Positive Width ,Negative Width ,Duty Cycle

Cursors Measurement: Voltage difference between cursors (V)Time difference between cursors (T)

Auto Counter: Resolution : 6 digits Accuracy : ±2% Signal Source: All available trigger source except the Video trigger mode

Frequency Range: 1kHz ~ 100kHz, 1kHz/STEP

Duty Cycle Range: 5% ~ 95%, 5%/STEP

Autoset: Automatically adjusts Vertical VOLTS/DIV, Horizontal TIME/DIV, and Trigger level

Save Setup: Up to 15 sets of measurement conditions

Save Waveform: 15 sets of waveform

TFT LCD Type: 5.6 inch

Display Resolution: 234(Vertically) x 320(Horizontally) Dots

Display Graticule: 8 x 10 divisions

Display Brightness: Adjustable

USB Slave Connector: USB1.1 & 2.0 full speed compatible (printers and flash disk not supported)

SD Card Slot: Image (BMP), waveform data (CSV), and setup (SET)

Line Voltage Range: AC 100V ~ 240V , 48Hz ~ 63Hz , Auto selection

Multi-Language Menu: Available

Onscreen Help: Available
