| Specifications |
| Full Scale | 199999 Counts |
| Sample Rate | Slow - 5 1/2 digits, 10 readings/second
Medium - 4 1/2 digits, 30 readings/second
Fast - 3 1/2 digits, 60 readings/second |
| DC Voltage |
| Range accuracy | 100mV, 1V, 10V, 100V, 1000V, 5 ranges +/- (0.012% rdg + 5 digits) |
| Input Impedance | 10MΩ |
| AC Voltage True RMS (AC or AC+DC True RMS) |
| Range | 100mV, 1V, 10V, 100V, 750V 5 ranges |
| Accuracy | 20Hz~45Hz +/- (1% rdg + 10 digits)
45Hz ~ 10kHz +/- (0.2% rdg + 100 digits)
10kHz ~ 30kHz +/- (1% rdg + 100 digits)
30kHz~100kHz +/- (3% rdg + 200 digits) |
| Input Impedance | 10MΩ |
| DC Current |
| Range | 10mA, 100mA, 10A 3 ranges |
| Accuracy | 10mA , 100mA +/- (0.05% rdg + 15 digits)
10A range +/- (0.2% rdg + 5 digits) |
| AC Current True RMS (AC or AC+DC True RMS) |
| Range Accuracy | 10mA, 100mA, 10A 3 ranges 10mA, 100mA, 10A
3 ranges: 20Hz ~ 50Hz +/- (1.5% rdg + 100 digits)
50Hz ~ 10kHz +/- (0.5% rdg + 100 digits)
10kHz~20kHz +/- (2% rdg + 200 digits) |
| Resistance |
| Range | 100Ω , 1kΩ , 10kΩ , 100kΩ , 1MΩ , 10MΩ , 100MΩ - 7 ranges |
| 2W Accuracy | 100Ω range +/- (0.1% rdg + 8digits)(*);1kΩ ~ 1MΩ 4 ranges +/- (0.08% rdg + 5 digits)
10MΩ range +/- (0.3% rdg + 5 digits);100MΩ range +/- (3% rdg + 8 digits) |
| 4W Accuracy | 100Ω range +/- (0.05% rdg + 8digits)(*);1kΩ ~ 1MΩ 4 ranges +/- (0.05% rdg + 5 digits)
10MΩ range +/- (0.3% rdg + 5 digits);100MΩ range +/- (3% rdg + 8 digits) |
| Diode Test |
| Open Circuit Voltage 2.0V, Test Current 0.5mA |
| Frequency |
| 20Hz~300kHz |
| Continuity Beeper |
| 1 ~ 1000Ω |
| Temperature |
| 0 C ~ 300 C - J , K , T Type |
| Other Functions |
| Auto range / Manual, Math - MX + B/ % / 1/X ; Max, Min, dBm, dB, REL, Hold, Compare, Store, Recall |
| Display |
| VFD, Two ColorsDual Display |
| Interface |
| Standard | Remote I/O, USB, RS-232C |
| Option | GPIB, Scanner Card |
| Power Source |
| AC 100V~240V +/- 10%, 50/60Hz |
| Attributes |
| Dimensions | 265(W) x 107(H) x 350(D) mm |
| Weight | Approx. 2.6 kg |
