DC Voltage |
Range: |
200mV, 2V, 20V, 200V, 1000V in 5 ranges |
|
Accuracy: |
±(0.006% reading + 2 digits) ~ ±(0.007% reading + 2 digits) |
|
Input Impedance: |
10MW, 1GW (200mV and 2V ranges) |
AC Voltage
(True RMS) |
Range: |
200mV, 2V, 20V, 200V, 750V in 5 ranges |
|
Accuracy: |
±(0.35% reading + 100 digits) ~ ±(5% reading + 400 digits) depending on range and frequency |
|
Input Impedance: |
10MW |
|
DC Current |
Range: |
200µA, 2mA, 20mA, 200mA, 2000mA in 5 ranges |
|
Accuracy: |
±(0.1% reading + 15 digits) ~ ±(0.2% reading + 15 digits) |
AC Current
(True RMS) |
Range: |
200µA, 2mA, 20mA, 200mA, 2000mA in 5 ranges |
|
Accuracy: |
±(0.8% reading + 100 digits) ~ ±(1.5% reading + 200 digits) |
|
Resistance |
Range: |
200W, 2k, 20k, 200k, 2M, 20M in 6 ranges |
|
Accuracy: |
±(0.014% reading + 2 digits) ~ ±(0.12% reading + 2 digits) |
|
dBm (ref: 600W) |
Accuracy: |
±(0.02dB + 1 digit) above -78dBm |
|
Resolution: |
0.01dB above 0.5% range |
|
Other Details |
Display: |
0.5" LCD display |
|
Power Source: |
AC 100V/120V/220V/240V ±10%, 50/60Hz |
|
Accessories: |
Power cord x 1, Instruction manual x 1, Test lead (GTL-107) x 1 |
|
Dimensions: |
230mm (w) x 95mm (h) x 280mm (d) |
|
Weight: |
2.4kg approx |
