General Specifications |
|
Range |
200pF, 2nF, 20nF, 200nF, 2uF, 20uF, 200uF, 2mF, 20mF in 9 ranges |
|
Accuracy |
200pF to 200uF +(1% rdg +2 digits), |
|
2mF~20mF + (2% rdg +10 digits) |
|
Dissipation factor |
Range: 0 to 1.999 |
|
Accuracy: 2nF < Cx <2uF +(1% +10 + 2000/Cx) |
|
2uF
|
|
200pF, 20mF not specified |
|
Range |
200uH, 2mH, 20mH, 200mH, 2H, 20H, 200H in 7 ranges |
|
Accuracy |
200uH, 2H~20H+(2% rdg + 2 digits) |
|
2mH to 200mH+(1% rdg + 2 digits) |
|
200H+(3%rdg + 2 digits) |
|
Dissipation |
Range 0 to 1.999 |
|
Factor |
Accuracy: Lx + 200mH + (1% + 10 + 2000/Lx) |
|
200mH to 200H + (2% + 20 + 2000/Lx) |
|
Range |
2Ω, 20Ω ,200Ω , 2kΩ , 20kΩ , 200kΩ ,2MΩ, 20MΩ in 8 ranges |
|
Accuracy |
2Ω +(1% rdg+ 5 digits) |
|
20Ω to 200kΩ +(1% rdg+ 2 digits) |
|
2MΩ to 20MΩ +(2% rdg+ 2 digits) |
|
Low battery warning |
Shows LO BAT when the battery level reaches 5% |
|
Current consumption |
10mA |
|
Temperature |
Operation 0°C to +40°C, Storage -20°C to +70°C |
|
Display |
0.5 inch digital height, 3½ digits LCD |
|
Power source |
Single 9V 006P battery |
|
Dimensions |
88(W) × 40(H) × 177(D)mm |
|
Weight |
Approx. 400g |
