| Rated Voltage |
AC 5A |
| Output Voltage |
10mV/A (AC 50mV/AC 5A) (AC 500mV/AC 50A) |
| Measuring Range |
AC 0 ~ 50Arms (70.7 Apeak) |
| Accuracy (Input : Sine Wave) |
±0.5%rdg ± 0.1mV(50/60Hz)
±1%rdg ± 0.2mV(40~1KHz) |
| Phase Characteristics |
±2deg within (at 0.5 ~ 50A/45 ~ 65Hz) |
| Temperature & Humidity Range (Guaranteed Accuracy) |
23±5°C, relative humidity : 85% or Less (no condensation) |
| Operating Temperature Range |
0 ~ 50°C, relative humidity : 85% or Less (no condensation) |
| Storage Temperature Range |
-20 ~ 60°C, relative humidity : 85% or Less (no condensation) |
| Maximum Permissible Input |
AC 50Arms continuous (50/60Hz) |
| Output Impedance |
Approx. 19Ω |
| Location for Use |
Altitude up to 2000m, Indoors |
| Applicable Standards |
IEC 61010-1< IEC 61010-2-032
Measurement CAT. III (300Vrms)
pollution degree 2, IEC 61326 |
| Wishtand Voltage |
AC 3540Vrms (50/60Hz) for 5 sec,
between Jaw and enclosure
between enclosure and output terminal,
between Jaw and output terminal |
| Insulation Resistance |
50MΩ or greater at 1000V,
between Jaw and enclosure
between enclosure and output terminal,
between Jaw and output terminal |
| Conductor Size |
Approx. 24mm in diameter (max.) |
| Dimension |
100(W) x 60(H) x 26(D) mm |
| Cable Length |
Approx. 1.2m |
| Output Terminal |
BNC |
| Weight |
Approx. 160g |
| Accessories |
Cable marker, Instruction manual |
