Hioki 9742 Optical Sensor

Name: Hioki 9742 Optical Sensor
Brand: Hioki
SKU: Hioki9742
Price: 416.00 USD
Availability: InStock

0 reviews | Model: Hioki 9742

Compare

Optical Sensor for 3664

View Product Details

List Price: $416.00

In Stock:

Recommended for you

Measurement wavelength	320 to 1100 nm
Acceptable power range	-59 dBm to +17 dBm at the calibration wavelength
Maximum rating	50 mW (+17 dBm) with total irradiation
Detector type	Si photodiode
Dimensions of lightreceiving area	Approx. 9.6 mm x 9.6 mm
Measurement accuracy	±4.3% Calibration conditions: Direct a 100 µW collimated He-Ne laser beam (approx. 2 mm dia) with a wavelength of 633 nm perpendicularly into the center of the sensor. Accuracy is ±5% when the sensor is used with the 3664.
Default wavelength settings	633 nm, 635 nm, 650 nm, 780 nm These are the default wavelengths stored in memory by the 3664. They cannot be edited.
Operating temperature and humidity ranges	0 to 40°C (32 to 104°F), 80% RH or less (no condensation)
Storage temperature and humidity ranges	-10 to 50°C (14 to 122°F), 80% RH or less (no condensation)
Accuracy guarantee for temperature and humidity	23 ± 5°C (73 ± 9°F), 80% RH or less
Guaranteed accuracy period	1 year
Location for use	Indoors, altitude up to 2000 m (6562-ft.)
Dimensions	Approx. 18W x 180H x 20D mm (0.71”W x 7.09”H x 0.79”D) (excluding projections) Cable lengths Approx. 2000 mm (78.74”)
Mass	Approx. 100 g (3.5 oz.)
Applicable Standards	Safety:EN 61010-1:2001 Pollution degree 2

Test Equipment General Attributes
Product Height	2.00 IN
Product Length	8.50 IN
Product Width	6.25 IN
ECCN Number	3A992
Country of Origin	Japan
Shipping Height	2.00 IN
Shipping Length	8.50 IN
Shipping Width	6.25 IN
