| Measurement Ranges: | AC Voltage: 100/200/500 V f.s. 3 ranges
AC Current: 10 A to 100 A AC 4 ranges (with optional 9650 CLAMP ON SENSOR), 10 A to 500 A AC 6 ranges (with optional 9651 CLAMP ON SENSOR), 10 A to 1000 A AC 7 ranges (with optional 9668 CLAMP ON SENSOR) |
| Frequency Characteristics: | AC/DC voltage range: +0.5 dB to -3 dB from 30 Hz to 30 kHz
AC current range: Frequency characteristic is determind by the clamp sensor. |
| Paper Feed Speed: | 60 cm/hour to 2 cm/hour, 5 ranges |
| Number of Input Channels: | 1 channel AC voltage and 1 channel AC current |
| Accuracy: | Voltage: ±2 % f.s. (45 Hz to 66 Hz)
Current: ±3.53 % f.s. (used with 9651 CLAMP ON SENSOR / option, AC 500 A range) |
| Power Supply: | 100 to 240 V AC (50/60 Hz) or 9.5 to 14 V DC, 2 way |
| Dimensions: | 250 mm(9.4 in)W × 122 mm(4.8 in)H × 93.5 mm(3.66 in)D |
| Accessories: | 9235 Recording paper (1 roll), roll paper holder (2), Power cord (1), 9257 CONNECTION CORD (1), 9344 CARRYING CASE (1) |
