| Measurable Cable: | UTP cable: Characteristic impedance 100 ohm , CAT 3, 4, 5, 5e |
| WireMap Check: | Can check wiring status using the 9336 WIREMAP TERMINATOR
Error detection: Open, short, other wiring errors
(Split pairs cannot be detected.) |
| Cable Length Check: | Measured length: 2 to 300m; When results are displayed in feet: 6.6 to 984 ft
Measurement accuracy: ? (15% rdg. + 1 m); When results are displayed in feet: ? (15% rdg. + 3.3 ft)
Display resolution: 0.1 m; When results are displayed in feet: 0.3 ft |
| Direction Check: | Can identify five cables using the optional 9337 DIRECTION TERMINATOR |
| Power Supply: | LR6(AA) alkaline battery ? 6, Continuous use 250 hours (when measuring once per minute) |
| Dimensions: | 98 mm(3.86 in)W ? 160 mm(6.30 in)H ? 38 mm(1.50 in)D |
| Accessories: | 9336 WIREMAP TERMINATOR(1), 3853 CARRYING CASE(1) |
