Hioki 3638-20 Leak Logger

Name: Hioki 3638-20 Leak Logger
Brand: Hioki
SKU: Hioki3638-20
Availability: InStock

0 reviews | Model: Hioki 3638-20

Compare

Leakage Data Logger

Select from three types of clamp on leak current sensors
Compact, light weight (130g), two-channel recording
High-capacity recording (32,000 data points)
Recording interval: 15 steps from 1 second to 60 minutes
Accurate true effective value calculation even for distorted waveforms (100/1000 mA)
Maximum or average value recording (max./ave. within recording interval)
View recording data graphically on a PC
Data is protected during battery discharge and replacement

Additional Photos
Click image to enlarge

View Product Details

In Stock:

View Payment Options

Recommended for you

The 3630 Data Logger Series are compact data loggers that are not much larger than a business card and weigh a mere 70 to 130 grams. Easy to operate, these handy instruments can record up to 16,000 or 32,000 data elements, and store data in nonvolatile memory that retains information even if the batteries are dead. The Data Logger Series includes models that can read temperature/humidity, instrumentation readings, voltage, current and other special types of data, and can be used in a broad range of measurements, including HACCP and ESCO applications. Data recorded in a DATA LOGGER can transferred to a personal computer through the 3911-20 Communication Base. Once the data is loaded into a personal computer, it can be processed, graphically displayed and managed on the PC.

Measurement Items:	AC leak current (with clamp-on leak sensor, sold separately)
Input Channels:	2 Channels
Measurement Range:	100.0 and 1000 mA (manual range selection)
Accuracy:	?1% rdg. ?5 dgt. at 50/60 Hz, 23 ?5?C, with built-in filter for 50/60Hz
Data Memory:	32,000 data points X 2ch (1 minute intervals, total 11 days), 16,000 data points X 1ch (1 minute interval, total 22 days)
Recording Interval:	1 to 30 seconds, 1 to 60 minutes, 15 settings
Power Supply:	4 x 1.5 V, LR03 (AAA) alkaline dry cell batteries, lifetime approx. 1 year (recording interval 1 minute)
Dimensions:	57.5 mm(2.26 in)W ? 86.5 mm(3.41 in)H ? 30 mm(1.18 in)D
Weight:	130 g (4.6 oz)
Accessories:	LR03 alkaline dry cell batteries (4), 9632 CONNECTION CABLE (for alarm output, 1)
