| Measurement Parameters: | |Z|, |Y|, phase angle, Rp(DCR), Rs(ESR, DCR), G, X, B, Cp, Cs, Lp, Ls, D(dissipation factor), and Q |
| Measurement Method: | Source: constant current 10 µA to 100 mA(AC/DC), or constant voltage 10 mV to 5 V (AC/DC)
Sense: voltage, AC or DC |
| Measurement Ranges: | |Z|, R, X: 10.00 m-Ohm to 200.00 M-Ohm (depending on condition), phase angle: -180.00 to +180.00°
C: 0.3200 pF to 1.0000 F, L: 16.000 nH to 750.00 kH, D: 0.00001 to 9.99999, Q: 0.01 to 999.99,
|Y|, G, B: 5.0000 nS to 99.999 S |
| Basic Accuracy: | |Z|: ±0.08 % rdg. , phase angle: ±0.05 ° |
| Measurement Times: | Fast: 5 msec. to Slow2: 828 msec |
| Display: | 99999 full digits, LCD with backlight display |
| Comparator Functions: | Setting: Upper and lower limit, percentage, or absolute value
Output: 3 levels (Hi, In, Lo), Open-collector, Isolated |
| External Printer: | 9442 (use with the 9443-02 or -03/9446/9593-01) |
| Power Supply: | 100 to 240 V AC (Selectable type) 50/60 Hz |
| Dimensions: | 313 mm(12.32 in)W × 125 mm(4.92 in)H × 290 mm(11.42 in)D |
