| AC Current range |
60.00 mA/ 600.0 mA/ 6.000 A/ 60.00 A/ 600.0 A, 5 ranges (40 Hz to 1 kHz, True RMS) Basic accuracy (45-66 Hz): ±1.5% rdg ±5 dgt (60.00 mA to 6.000 A), ±2.5% rdg ±5 dgt (60.00 A to 600.0 A) Guaranteed accuracy: from 0.60 mA to 600.0A |
| AC Voltage range |
N/A |
| Frequency range |
40.0 Hz to 999.9 Hz |
| Crest factor |
4.5 (4000 counts or less) 3 (more than 4000 counts, 6000 counts or less) |
| Filter function |
Cut off frequency: 180 Hz ±30 Hz at filter ON (-3 dB) |
| Output function |
N/A |
| Other functions |
Comparator function, record Max/Min/Avg value, backlight, data hold, auto power off, AC inrush function |
| Display |
Display refresh rate: 5 times/s |
| Power supply |
LR03 alkaline battery × 1; 32 hours of continuous use |
| Core jaw diameter |
φ 24 mm (0.94 in) |
| Dimensions and mass |
37 mm (1.46 in) W × 160 mm (6.30 in) H × 27 mm (1.06 in) D, 115 g (4.1 oz.) |
| Operating environment |
Indoors, pollution degree 2, operable at an altitude specified in specifications of each measuring instrument to which the adapter is attached |
| Operating temperature and humidity (Storage temperature and humidity) |
-30℃ (-22℉) to 70℃ (158℉), 90% RH or less (no condensation) |
| Standards |
Safety: EN61010
RF: EN300 328
RF EMC: EN301 489-1, EN301 489-17
Exposure: EN62479 |
| Maximum attaching/detaching count |
5000 times |
| GENNECT Cross App confirmed compatible OSs |
iOS 13 or later, Android 8 or later, Bluetooth® 4.0 or later |
| Bluetooth® communication distance |
About 10 m (line-of-sight distance) |
| Product warranty period |
3 years (do not exceed the maximum attaching/detaching count) |
| Dimensions and mass |
Approx. 16.4 mm (0.65in)W × 6.7 mm (0.26in)H × 15.6 mm (0.61in)D, 1.5 g (0.05 oz.) |
