| Rated Current: |
500 A AC/DC (Continuous 650 A) |
| Accuracy (at 45 to 66 Hz): |
±0.5% rdg ±0.05% f.s., phase ±0.2° |
| Output Rate (9555): |
2 V/rated current range (waveform output, with the 9555) |
| Max Circuit Voltage: |
600 V peak (insulated wire)
Note: The core, shield case, and electrical circuits are not insulated |
| Power Supply: |
9555 Sensor Unit (required) |
| Dimensions: |
220mm (W) x 103mm (H) x 43.5mm (D)
8.66in (W) x 4.06in (H) x 1.71in (D) |
