| Setting Pointer: |
Lance shape, upper limit and lower limit pointer |
| Minimum H/L Interval: |
Within 3 % of scale length |
| Relay Power Delay Circuit: |
Approx. 2 second |
| Output Contact Capacity: |
5 A (under condition of 250 V AC, 30 V DC, resistance load) |
| Power Supply: |
100 or 200 V AC ±10 % (to be specified at the time of ordering) |
| Dimensions: |
84 mm(3.31 in)W(panel size) × 72 mm(2.83 in)H (panel size) × 117.6 mm(4.63 in)H (rear section)
|
