Hart Scientific 9210

Name: Schema+Brands 9210
Brand: Hart Scientific
SKU: Hart Scientific9210
Price: 6455.00 USD
Availability: InStock

0 reviews | Model: Hart Scientific 9210

Compare

Maintenance System, Mini TPW Cells

Stability to ±0.0007°C
Best digital temperature controller available
“Super Tweak” function provides set-point resolution to 0.00003°C
Excellent for maintaining fixed-point cells
We ship Hart Scientific products only within the United States and United States territories. This DOES include US military working abroad. If you have any questions about this policy please call - 1-877-742-8378.

View Product Details

List Price: $6,455.00

In Stock:

View Payment Options

Recommended for you

The triple point of water (0.01°C) is one of the most important temperatures on the ITS-90. Unfortunately, realizing and maintaining triple point of water cells hasn’t always been convenient or cost-effective. ,br>
Because ITS-90 calibrations require frequent measurements at the triple point of water, and because the triple point of water is often used as a statistical check against the drift of a temperature standard, it is important to be able to realize and maintain well-constructed triple point of water cells easily.

Hart’s 9210 TPW Maintenance Apparatus provides built-in programming for the simple supercool-and-shake realization and maintenance of our Model 5901B Mini TPW Cell. Simply insert the cell, enter the “freeze” mode through the front-panel buttons, have your morning cup of coffee, and when the 9210 audibly alerts you, remove the Mini TPW Cell and give it a shake to initiate freezing a portion of the water. Re-insert the cell, change the program mode to “maintain,” and you’ve got 0.01°C for the rest of the day with uncertainty of only ±0.0005°C.

Precision-machined thermal blocks can also be used to take advantage of the excellent stability and uniformity of the 9210 for performing comparison calibrations. Multi-hole and custom blocks are available with 7-inch depths.

Temperature Range	–10°C to 125°C
Ambient Operating Range	5°C to 45°C
Stability	±0.02°C
Vertical Gradient	±0.05°C over 100 mm at 0°C
Melting/Freezing-Point Duration	6–10 hours, typical
Resolution	0.01° (0.001° in program mode)
Display Scale	°C or °F, switchable
Immersion Depth	6.75" (171 mm) in optional comparison block
Stabilization Time	15 minutes nominal
Preprogrammed	15 minutes nominal
Preheat Wells	3 wells (for 3.18, 6.35, or 7.01 mm probes)
Fault Protection	Adjustable software cutout using control probe, separate circuit thermocouple cutout for maximum instrument temperature
Heating/cooling rate cutout	Sensor burnout and short protection, over-temperature thermal cutout
Display Accuracy	±0.25°C
Comparison Block	Three multi-hole blocks, blanks, and custom blocks available
Well-to-Well Gradient(in comparison block)	±0.02°C
Heating Time	Ambient to 100°C: 45 min.
Cooling Time	Ambient to –5°C: 25 min.
Communications	RS-232 included
Power Requirements	115 VAC (±10%), 60 Hz, 1.5 A, 230 VAC (±10%), 50 Hz, 0.75 A, 170 W
Exterior Dimensions	8.75" W x 10.25" D x 19.25" H (222 x 260 x 489 mm)
Weight	15.5 lb. (7 kg) with block
