| 6330 | 7320 | 7340 | 7380 |
Range | 35°C to 300°C | –20°C to 150°C | –40°C to 150°C | –80°C to 100°C |
Stability | ±0.005°C at 100°C (oil 5012) ±0.010°C at 200°C (oil 5017) ±0.015°C at 300°C (oil 5017) | ±0.005°C at –20°C (ethanol) ±0.005°C at 25°C (water) ±0.007°C at 150°C (oil 5012) | ±0.005°C at –40°C (ethanol) ±0.005°C at 25°C (water) ±0.007°C at 150°C (oil 5012) | ±0.006°C at –80°C (ethanol) ±0.010°C at 0°C (ethanol) ±0.010°C at 100°C (oil 5012) |
Uniformity | ±0.007°C at 100°C (oil 5012) ±0.015°C at 200°C (oil 5017) ±0.020°C at 300°C (oil 5017) | ±0.005°C at –20°C (ethanol) ±0.005°C at 25°C (water) ±0.010°C at 150°C (oil 5012) | ±0.006°C at –40°C (ethanol) ±0.005°C at 25°C (water) ±0.010°C at 150°C (oil 5012) | ±0.008°C at –80°C (ethanol) ±0.012°C at 0°C (ethanol) ±0.012°C at 100°C (oil 5012) |
Heating Time† | 250 minutes, from 35°C to 300°C (oil 5017) | 80 minutes, from 25°C to 150°C (oil 5012) | 60 minutes, from 25°C to 150°C (oil 5012) | 25 minutes, from 25°C to 100°C (oil 5010) |
Cooling Time | n/a | 100 minutes, from 25°C to –20°C (oil 5012) | 110 minutes, from 25°C to –40°C (ethanol) | 130 minutes, from 25°C to –80°C (ethanol) |
Stabilization Time | 15–20 minutes |
Temperature Setting | Digital display with push-button data entry |
Set-Point Resolution | 0.01°; 0.00018° in high-resolution mode | 0.01° |
Display Resolution | 0.01° |
Digital Setting Accuracy | ±0.5°C |
Digital Setting Repeatability | ±0.01°C |
Access Opening | 3.7" x 6.8" (94 x 172 mm) | 3.25" x 4.5" (86 x 114 mm) |
Working Area | 3.2" x 5.25" (81 x 133 mm) | 3" x 4" (86 x 114 mm) |
Depth | 9.25" (234 mm) | 7" (178 mm) |
Wetted Parts | 304 stainless steel |
Power | 115 VAC (±10%), 50/60 Hz, 7A or 230 VAC (±10%), 50/60 Hz, 3.5A, specify | 115 VAC (±10%), 60 Hz, 15 A or 230 VAC (±10%), 50 Hz, 8 A, specify, 1400 VA | 115 VAC (±10%) 60 Hz, 16 A or 230 VAC (±10%), 50 Hz, 8 A, specify |
Volume | 2.4 gal (9.2 liters) | 1 gal (4 liters) |
Size | 12" W x 21.5" D x 18.5" H (305 x 546 x 470 mm) off cart; 12" W x 21.5" D x 32.25" H (305 x 546 x 819 mm) on cart | 12" W x 24.5" D x 23" H (305 x 622 x 584 mm) off cart; 12" W x 24.5" D x 32.25" H (305 x 622 x 819 mm) on cart | 12" W x 24" D x 30" H (305 x 610 x 762 mm) |
Weight | 42 lb. (19 kg) | 78 lb. (35.4 kg) | 115 lb. (52 kg) |
Automation Package | Interface-it software and RS-232 included (IEEE-488 optional) |
†Rated at nominal 115 V (or optional 230 V) |
