Hammond 2CPT206036 60" Standard Modular Console System Turret Unit - 20 x 60 x 16.625 - Steel/Gray

Name: Hammond 2CPT206036 60" Standard Modular Console System Turret Unit - 20 x 60 x 16.625 - Steel/Gray
Brand: Hammond
SKU: Hammond2CPT206036
Price: 1164.27 USD
Availability: InStock

0 reviews | Model: Hammond 2CPT206036

Compare

60" Standard Turret - 20 x 60 x 16.625 - Steel/Gray

Cannot Ship Air

Application:

Ideal as a housing for video screens.
Flexible design provides panel mount or rack mount capabilities for a variety of applications.
Generally used in combination with other modular console components (ie. base, pedestal, and/or desk).
Available in either Standard (supported by Base, Pedestal, or Standard Desk) or Deep (supported by Deep Desk only) format.
Smooth lines and clean edges provide an attractive, contemporary appearance.

View Product Details

List Price: $2,181.33

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

Adapter Kits

for the Hammond 2CPT206036

Cal Test CT4103 Universal Adapter Kit

Catalog: CT4103

(9)

In Stock!

Add to Cart

Standards:
RAL 7032 Beige

UL 508 Type 12
CSA Type 12
EIA RS-310-D
Complies with:
NEMA Type 12
IEC 60529, IP5

ANSI 61 Gray

UL 508 Type 3R, 4, 4X, 12
CSA Type 3R, 4, 12, 13
EIA RS-310-D
Complies with:
NEMA Type 3R, 4, 12
IEC 60529, IP66

Stainless Steel (Type 304)

UL 508 Type 3R, 4, 4X, 12
CSA Type 3R, 4, 4X, 12
EIA RS-310-D
Complies with:
NEMA Type 3R, 4, 4X, 12
IEC 60529, IP66

Construction:

Formed 14 gauge steel bodies with 14 gauge steel doors.
Also offered with formed 14 gauge 304 stainless steel bodies with 14 gauge 304 stainless steel doors.
Smooth, continuously welded seams without knockouts or holes.
Body stiffeners are provided where required for increased strength and rigidity.
Offered in 4 widths 24", 36", 48" and 60".
Features solid sides and top, solid door on front (opens down) and back (opens up), and open bottom.
Front door features sliding rod mechanism, which allows a 102º opening when in the lowered position.
Rear door features manual, 3 position adjustable door stop which provides convenient support while door in open position.
Formed lip on enclosure excludes flowing liquids and contaminants.
Slotted quarter turn oil-tight latches secure the door, with optional tamper resistant and locking latches available.
Stainless steel models utilize stainless steel hardware.
Oil resistant gaskets are permanently secured and mechanically retained.
Features several internal stud locations for mounting of various accessories.
A bonding screw is provided on the door and a grounding stud is provided in the enclosure.

Finish:

Available in RAL 7032 beige powder coating, ANSI 61 gray powder coating and natural stainless steel with a smooth, brushed finish.
24" Front Window Door available in same finishes.

Accessories:
