| Technical Specifications |
| DC voltage |
| Measuring range |
0.0V ÷ 999.9V |
| Resolution |
0.1V |
| Accuracy |
±(0.5%reading + 2digits) |
| AC TRMS, DC, AC+DC TRMS, LoZ voltage |
| Measuring range |
0.5V ÷ 999.9V |
| Resolution |
0.1V |
| Frequency range |
32Hz ÷ 1kHz |
| Accuracy |
±(0.5%reading + 2digits) |
| AC TRMS current with flexible clamp F3000U |
| Measuring range |
1A ÷ 3000A |
| Basic resolution |
0.01A |
| Accuracy |
±(0.5%reading + 2digits) |
| AC TRMS, DC, AC+DC TRMS current with standard clamp |
| Measuring range |
1mV ÷ 1000mV |
| Resolution |
1mV |
| Accuracy |
±(0.5%reading + 2digits) |
| Inrush current (DIRC) - Flexible clamp F3000U |
| Measuring range |
1A ÷ 3000A |
| Basic resolution |
0.01A |
| Frequency range |
42.5Hz ÷ 69Hz |
| Accuracy |
±(2.0%reading + 2digits) |
| Response time of peak |
1ms |
| Max RMS response time |
16.6ms, 20ms, 50ms, 100ms, 150ms, 175ms, 200ms |
| Inrush current (DIRC) - Standard clamp |
| Measuring range |
1mV ÷ 1000mV |
| Resolution |
1mV |
| Frequency range |
42.5Hz ÷ 69Hz |
| Accuracy |
±(2.0%reading + 2digits) |
| Response time of peak |
1ms |
| Max RMS response time |
16.6ms, 20ms, 50ms, 100ms, 150ms, 175ms, 200ms |
| Resistance and Continuity test |
| Measuring range |
0.0Ω ÷ 1999Ω |
| Basic resolution |
0.1Ω |
| Accuracy |
±(1.0%reading + 5digits) |
| Buzzer test |
R<30Ω |
| Voltage / Current harmonics |
| Harmonic order |
DC, 1st ÷ 25th + THD% |
| Frequency range |
42.5Hz ÷ 69Hz |
| Resolution |
0.1V / 0.1A |
| Basic accuracy |
±(5.0%rdg + 10digits) |
| Phase sequence with 1 terminal |
| Measuring range |
100V ÷ 999.9V |
| Frequency range |
42.5Hz ÷ 69Hz |
| Insulation resistance |
| Test voltages |
50,100,250,500,1000VDC |
| Measuring range (@ 500V) |
0.01MΩ ÷ 999MΩ |
| Resolution |
0.01MΩ ÷ 1MΩ |
| Basic accuracy (@ 500V) |
±(2.0%reading + 2digits) |
| Timer for measurements |
15s, 30s, 1min, 5min, 10min |
| Continuity of protective conductors |
| Test current |
>200mA DC (@ R<5Ω) |
| Measuring range |
0.00Ω ÷ 199.9Ω |
| Open-circuit voltage |
4 < Vo < 12V DC |
| Accuracy |
±(2.0%reading + 2digits) |
| General characteristics |
| Instrument safety |
IEC/EN61010-1, IEC/EN61010-2-030, IEC/EN61010-2-033 |
| EMC |
IEC/EN 61326-1 |
| Test MΩ |
CEI 64-8, IEC/EN61557-2 |
| Test LoΩ |
CEI 64-8, IEC/EN61557-4 |
| Phase sequence |
IEC/EN 61557-7 |
| Insulation |
double insulation |
| Pollution level |
2 |
| Measurement category |
CAT IV 600V, CAT III 1000V to earth and between inputs |
| Mechanical characteristics |
| Size (L x W x H) |
175 x 85 x 55mm |
| Weight (batteries included) |
420g |
| Mechanical protection |
IP40 |
| Power supply |
| Battery type |
4x1.5V batteries type AAA IEC LR03 |
| Auto power off |
after 15 minutes’ idling |
| Display |
| Type of display |
4 dgt LCD, max 9999 dots, decimal sign, point, backlight and bargraph, indication of polarity |
| Updating frequency |
2 times/s |
