| Amperage Measurement |
600, 6000 MICAMP, 60, 600 MILAMP, 6, 10 AMP |
| Battery |
(1) 9 V |
| Capacitance |
60, 600 NFDN 6, 60, 600 MFD, 6, 25 MILFD |
| Conductance |
99.99 nS |
| Display |
Backlit LCD Displays 2 Readings With 10,000 Count Resolution |
| Frequency Measurement |
15 HZ - 50 KHZ Sine Wave, 5 HZ - 1 MHZ Logic Level Square Wave |
| Includes |
(1) 9V Battery, Bead Temperature Probe (400 DEG F/204 DEG CMax), Test leads, Protective Boot, Carrying Case |
| Measurement Category |
CAT IV, 1000 V |
| Replacement Part |
TC-20 Carrying Case, TSG-3 Sure-Grip Test Leads, TPB Bead Temperature Probe |
| Resistance Measurement |
600 OHM, 6, 60, 600 KOHM, 6, 60 MOHM |
| Standard |
CAT IV, C/UL US Listed, TRUE RMS, CE Listed |
| Temperature Rating |
K Type, -58 To 1832 DEG F (-50 To 1000 DEG C) |
| Type |
Digital |
| Voltage Measurement |
60.00, 600.0 MILV, 9.999, 99.99, 999.9 V |
