| Basic Specifications | GL450 |
| Number of analog input terminal units | 2 |
| Sampling interval *1 | 100 ms (10 ch) - 1 h |
| Trigger | Type | Start (Data capture starts when a trigger is generated)
Stop (Data capture stops when a trigger is generated) |
| Condition | Start: Level, Alarm, External, Off
Stop: Level, Alarm, External, Time, Off |
| Alarm | Type | Analog, Logic, Pulse (AND and OR operations available) |
| Condition | Analog: H, L, Window In, Window Out
Logic: 4-ch pattern
Pulse: H, L, Window In, Window Out |
| Number of channels for logic input | 4 ch |
| Number of channels for pulse input | 1 ch |
| Pulse input range | Count mode | 50 kc, 500 kc, 5 Mc, 50 Mc, 500 Mc/f.s. (max. 50 k/sampling interval) |
| Inst. mode | 50 kc, 500 kc, 5 Mc, 50 Mc/f.s. (max. 50 k/sampling interval) |
| RPM mode | 500 rpm, 5 krpm, 50 krpm, 500 krpm/f.s. (max. 50 k/sec) |
| Alarm output | Number of channels | 4 ch |
| Output format | Open collector output (100 kO pull-up resistance) |
| Output conditions | Level judgment, Window judgment, Logic Pattern judgment, Pulse judgment |
| External trigger input*2 | 1 ch |
| Interface to PC | Ethernet (10BASE-T/100BASE-TX), USB2.0 |
| Internal memory | 4 MByte |
| PCMCIA slot | Type 2 compatible |
| Monitor | Size | 4.7-inch STN color LCD |
| Displayed items | Waveforms + digital values, waveforms only, digital values only |
| Functions | Expanded/compressed waveform displays, scaling, statisticalcalculations, search |
| Operating environment | Temperature: 0 - 40?C, Humidity 30 - 80% RH |
| Power supply | AC adapter (100 to 240 VAC, 50/60Hz), DC power (8.5 to 24 VDC) *3, battery pack *3 |
| Power consumption | External dimensions (W x D x H, approx.) 212 x 152 x 45mm |
| Weight (approx.) | 770g *4 |
