| General Specification |
| Number of analog terminal units |
Maximum 10 units (200CH) |
| How to connect Analog Terminal Unit |
Direct-connect or connect with the extension terminal connection cable (sold separately)
between the GLT400 and terminal unit, or between terminal units. Cables are 50cm or 2m length |
| Memory devices |
| Memory capacity(*1) |
Internal memory (MEM)：approx. 4GB
SD CARD slot：1 (Compatible with SDHC, up to approx. 32GB memory available. The memory format only supports FAT/FAT32. ) |
| Memory contents |
Setup conditions, Measured data |
| PC Software |
Standard Accessories (GLT400 Setting App, GL-Connection） |
| PC I/F |
| Types |
Ethernet(10BASE-T/100BASE-TX),USB 2.0,Wireless LAN (Option) |
| Functions |
Setup and control of the GLT400 from PC, Data transfer to the PC ,Connect to network as a remote terminal unit of GL840 |
| Ethernet functions |
Web server functions, FTP server function, FTP client function,NTP client function,DHCP client function,Modbus/TCP Protocol |
| USB functions |
USB drive mode：Transfer and delete the captured les in the internal memory or SD CARD |
| Operating Environment |
-20 to 60°C (Temperatures vary by analog terminal, AC adapter: 0 to 45°C)
5 to 85%R.H.(non condensed)(When using the USB PD as the power supply, the spec. is based on power supply requirements.) |
| Power source |
| AC adapter |
100 to 240 V AC, 50/60 Hz |
| DC power |
8.5 to 24V DC (maximum 26.4V) (DC drive cable (option B-514) is required) |
| USB PD |
USB PD compatible, external USB PD compatible battery (USB Power Delivery Revision 2.0 later) |
| External dimensions (approx.) [W×D×H（] *2） |
Input terminal (B-564) or Screwless terminal (B-564SL) is attached: 187.5 × 183 × 65.5 mm (excluding protrusions)
Input terminal (B-565): 187.5×183×65.5mm (excluding protrusions) |
| Weight (approx.)（*2） |
1120g (In case input terminal (B-565) is attatched: Di er according to terminal type) |
| Others |
Vibration -tested condition: Automobile parts Type 1 Class A equivalent |
*1 : Possible to save up to 2GByte for one le
*2 : Main unit, Anlalog terminal and Terminal base unit are installed. AC adapter is not included in dimensions and weight speci cation. |
