Gossen Metrawatt M550C Test Instrument for Insulation, Low-resistance and Voltage Measurements

Name: Gossen Metrawatt M550C Test Instrument for Insulation, Low-resistance and Voltage Measurements
Brand: Gossen Metrawatt
SKU: GossenM550C
Price: 886.00 USD
Availability: InStock

0 reviews | Model: Gossen Metrawatt M550C

Compare

METRISO G1000Test Instrument for Insulation, Low-resistance and Voltage Measurements

Digital and analogue display, backlit
Intelligent filter - precise and measurement-dependent activation for the measurement of very high resistances
- beating, i. e. compensation of 16 2/3 Hz and 50 Hz interference
- attenuation of capacitive influences from power cables, etc.
- suppression of electric field influences
Signalling of dangerous contact voltage by means of LED
Indication of limit value violations by means of LED
Overvoltage protection - protects the instrument in the event of inadvertent connection to mains power
Fuse link for all resistance measuring ranges
New: Electronic fuse for protection of the low-resistance measurement RLO also protects the fuse link in the low-resistance measuring range in the event of faulty operation
One measuring point self-test with test resistance of 10 MΩ per EN 50110 / VDE 0105-100
Guard terminal for compensating surface current

View Product Details

List Price: $886.00

In Stock:

View Payment Options

Recommended for you

Accessories

Choose a Category

for the Gossen Metrawatt M550C

Gossen Metrawatt Z550C Ever-Ready Case for METRISO INTRO, BASE, TECH, XTRA and...

Catalog: METRISO-PROFITEST Ever-Ready Case

(0)

In Stock!

Add to Cart

Gossen Metrawatt Z550A Test Probe With Remote Triggering

Catalog: Test probe with remote triggering, METRISO-PROFITEST

(0)

In Stock!

Add to Cart

Gossen Metrawatt Z502U Magnetic test probes with touch protection set with magnetic...

Catalog: Measuring probes, 4 mm plug

(0)

In Stock!

Add to Cart

Gossen Metrawatt M662A Calibration Adapter for Testing the Accuracy of Instruments

Catalog: ISO Calibrator 1

(0)

In Stock!

Add to Cart

The METRISO G1000 insulation and resistance measuring instruments allow for quick and effective testing of protective measures in accordance with:
- DIN VDE 0100
- ÖVE-EN 1 (Austria)
- SEV 1000 (Switzerland)
- and regulations specific to other countries as well

Insulation measurement per EN 61557-2 / VDE 0413 part 2
Low-resistance measurement per EN 61557-4 / VDE 0413 part 4
Voltage testing and measurement up to 1000 V

Compact and rugged - for service calls under harsh conditions and laboratory use

The insulation measuring instruments are suitable for the following tasks:

Measurement of insulation resistance at voltage-free devices and systems, up to 1000 V
Testing of the resistance of earthing conductors, protective conductors and equipotential bonding
Checking of test objects for absence of voltage
Testing of electrostatic discharge capacity at floor coverings (using shielded measurement cables) - EN 1081

1 Insulation and resistance measuring instrument
1 DAkkS calibration certificate
1 Set batteries
1 Carrying strap
1 Alligator clip (not METRISO G500MM (M550K))
1 KS17-4 cable set
1 Condensed operating instructions
1 CD ROM with the following content:
– Comprehensive operating instructions (English and German)
– Data sheet

Reference Conditions
Reference temperature	+ 23 °C +/-3 K
Relative humidity	40 ... 75%
Measured quantity frequency	45 Hz ... 65 Hz
Measured quantity waveshape	Sine, deviation between TRMS and rectified value < 1%
Battery voltage	9.5 V +/- 0.1 V
Test resistor	10 MΩ +/-1%
Electrical Safety
Protection class	II
Pollution degree	2
Measuring category G1000	CAT II 1000 V / CAT III 600 V / CAT IV 300 V
Fuse link	FF315mA/1000V, effective in all resistance measuring ranges, 1 additional replacement fuse in the battery compartment
Elektronic fuse	forprotecting low-resistance and resistance measurement RLO and R (not METRISO G500MM (M550K))
Ambient Conditions
Accuracy temperature range	0 ... +40 °C
Operating temperature	–10 ... +50 °C
Storage temp. range	–25 ... +70 °C (without batteries)
Relative humidity	Up to 75% (max. 85% during storage/transport), no condensation allowed
Elevation Max.	2000 m
Calibration interval	1 year (recommended)
Power Supply
Batteries	8 ea. 1.5 V mignon cell (8 ea. size AA) (alkaline manganese per IEC LR14)
Nominal range of use	8.5 ... 12 V
Mechanical Design
Dimensions	225 x 130 x 140 mm
Weight Approx.	1.4 kg with batteries
Protection Housing	IP 52, measurement cables and connectors: IP 40 per DIN VDE 0470, part 1 / EN 60529, housing category 2
Power Supply
Batteries	8 ea. 1.5 V mignon cell (8 ea. size AA) (alkaline manganese per IEC LR14)
Nominal range of use	8.5 ... 12 V

Tech Specs

Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers Template
Type	Hand Crank
Display (Megohmmeter)	Digital
Power Supply	Battery
CAT Rating	IV
CAT Voltage	1,000 V, 300 V, 600 V
Test Equipment General Attributes
Unique Features	Voltage testing and measurement up to 1000 V
Safety Approval	CE
IP Rating	IP40, IP52
Product Weight	1.4 KILOS (3.09 LBS)
Product Height	130 MM (5.12 IN)
Product Length	235 MM (9.25 IN)
Product Width	140 MM (5.51 IN)
Battery Type	AA
Power Supply Voltage	Battery Powered
Country of Origin	Germany
