TRMS System Multimeter, MetraHit X-TRA, Waterproof Multimeter for Field
The METRAHIT AM XTRA is the top-of-the-line instrument of the METRAHIT Advanced Multimeter series.
The multimeters of the METRAHIT AM series, including METRAHIT AM BASE, PRO, TECH, and XTRA, are extremely rugged, reliable digital multimeters with housings made of impact-resistant plastic. They feature an appealing design and are equipped with state-of-the-art technology.
The OUTDOOR multimeter has been specially designed and manufactured to meet the challenges faced by engineers and technicians in adverse environments. It´s extremely rugged, impact-resistant, water-proof, and dust-proof, and it is resistant to extreme temperatures.
METRAHIT OUTDOOR Technology and scope of functions are the same as with the METRAHIt X-TRA.
Product Highlights
- TRMSAC, AC+DC measurement up to 20 kHz for voltage and current
- Data logger and IR interface for PC
- Power pack connector socket
Advantages
- Universal use in all fields of electrical engineering!
- TRMS measurement up to 20 kHz with digital display (12000 digits) and analog scale
- Measurement of voltage and current, DC, AC and AC/DC, resistance, temperature, frequency, duty cycle, capacitance, continuity/diodes
- Automatic measuring range selection and measured value storage
- Safety for the user and the instrument in measuring categories CAT IV up to 600 V and CAT III up to 1000 V.
Applications
- The multimeter is suitable for universal use in electrical engineering, electrical installation, laboratory applications, telecommunication, training, etc.
- The instrument can be used in the field and is equipped with an internal, mains-independent power supply. The additional power pack connector socket is ideal for long-term measurements and laboratory use.
23 multimeter functions
- Voltage ACTRMS, voltage AC+DC TRMS, voltage DC, frequency (Hz, MHz), duty cycle, resistance, diode test, continuity test, capacitance, current ACTRMS, current AC+DC TRMS, temperature with Pt 100/1000 sensors, and type K thermocouples
- Auto-range current measurement from 100 µA (resolution: 10 nA) to10 A (16 A) via a single connector jack and a single fuse
- Additional filter function and voltage measurement with reduced input impedance for limiting interference, e.g., for measurements at frequency converters
- 540 kB data memory (15,400 measured values) for long-term measurements with data logger function
- Powerpack connector socket for operation without batteries
- Infrared interface for communication with the PC
- Rubber holster safeguards against shocks and impacts
Specific features of the OUTDOOR multimeter:
- Special rugged design with shock and impact-resistant housing and additional rubber holster
- Special "sand" color
- Dust-proof: IP 6x
- Water jets: IP x5
- Patented, sealed blocking sockets
