Gossen Metrawatt M235H ASi Bus Tester

Name: Gossen Metrawatt M235H ASi Bus Tester
Brand: Gossen Metrawatt
SKU: GossenM235H
Price: 451.00 USD
Availability: InStock

0 reviews | Catalog: M235H | Model: Gossen Metrawatt M235H

Compare

AS-I-Address- and Tester unit, GH, batteries, Z

Reads out slave addresses 0 ...31, A, B without scrolling - complete LCD overview display
Reads out slave IO and ID codes (including extended ID codes 1 and 2)
Standard addressing mode, and extended addressing mode per ASi version 2.1
Programming of ID code 1
Slave function-test, also for analog slaves with profile 7.2 (7.3 in preparation)
Recognition of all system components
Memory, diagnosis and PC gateway functions
Data transmission, data management and documentation of system parameters with optional software
Connection via jack plug

View Product Details

List Price: $451.00

In Stock:

Recommended for you

Choose a Category

(0)

In Stock!

Add to Cart

(0)

In Stock!

Add to Cart

Voltage
Measuring Range	2....35 V
Measuiring Accuracy	±(3.5% of rdg. + 2 d)
Current (for slaves)
Measuring Range	0....0.1 A
Measuiring Accuracy	±(5% of rdg. + 2 d)
Ambient Conditions
Operating Temperature Range	0 °C +50 °C
Storage Temperature Range	20 °C +75 °C (without batteries)
Relative Humidity	max. 75%, no condensation allowed
Elevation	to 2000 m
Deployment	indoors only
Mechanical Design
Protection housing	IP 50, jack sockets: IP 20
Dimensions	84 mm x 195 mm x 35 mm
Weight	approx. 450 gr. with batteries

Programmers / IC and RAM Testers/Programmers and IC Testers Template
Operations	Other Operations Diagnosis and Addressing
Test Equipment General Attributes
Unique Features	• Program ID code 1 • Slave functions test • Recognition of all devices within the system • Diagnosis functions • Memory functions • PC gateway function
Safety Approval	CE
Interfaces I/O	Other
Product Weight	450 GRAMS (0.992 LBS)
Product Height	84 MM (3.31 IN)
Product Length	195 MM (7.68 IN)
Product Width	35 MM (1.38 IN)
Battery Type	Other Battery Type IEC LR6
Power Supply Voltage	Battery Powered
Country of Origin	Germany
