Until now, buying a truly low cost logic analyzer meant buying a very limited product with a limited number of channels, limited speed, limited trigger capabilities and limited display facilities.

The GA320S is a product that meets the needs of all but the most demanding of applications. Thirty-two data channels, 100MHz maximum acquisition speed, 5ns glitch capture and multi-level trigger sequencing.

The capabilities of a logic analyzer have become important within virtually every area of electronics. Development, production, service and education all have a need for logic analysis, but the high prices have affected their accessibility. Now Global Specialties has made high performance logic analysis affordable.

The GA320S is a high performance, low-cost, portable logic analyzer for development, production and field-service applications. It can capture data across 32 channels (at 25MHz) at up to 100MHz (8 channels) and display it in both Timing and List formats on the built-in supertwist LCD or on a PC screen.

The GA320S features multi-level triggering with event counting and restart. Glitch capture and glitch triggering are also available with the appropriate input pods. The three external clocks have independent qualifiers and both data and clock pod inputs can be fixed (TTL) or variable threshold depending on pod choice.

All functions are accessed through easy to follow soft-key controlled displays. The use of soft-keys guides the user and minimizes the number of keystrokes required to achieve the desired function. Alternatively, the GA320S can be fully remote-control via its RS-232 serial interface from a PC which offers an enhanced soft-key orientated user interface and more sophisticated data displays.
